2. PERFORMANCE
- 7 -
2.1 System Overview
2. PERFORMANCE
Item Specification
Shape GSM 850/900/1800/1900 and WCDMA850/1900 - Bar type Handset
Size 108 X 54.8 X 12.9 mm
Weight 93 g (include 1,000mAh Battery )
Power 3.7 V normal, 1000 mAh Li-ion
Talk Time Over 180 min ↑ (WCDMA, Tx=12 dBm, Voice)
(with 1000mAh) Over 180 min ↑ (GSM, Tx=Level 5, Voice)
Standby Time Over 250 Hrs ↑ (WCDMA, DRX=1.28)
(with 1000mAh) Over 250 Hrs ↑ (GSM, Paging period=6)
Antenna Internal type
LCD TFT WQVGA LCD(3°Ø, 262K, 240 x 400)
LCD Backlight White LED Back Light
Camera Auto Focus - 2.0 Mega pixel (CMOS)
Vibrator Yes (Coin Type)
MIC Yes
Receiver Yes
Earphone Jack Yes (18 pin)
Connectivity Bluetooth, USB
Volume Key Push Type (+, -)
External Memory Yes
I/O Connect 18 Pin
