10. Calibration & RF Auto Test Program (Hot Kimchi)
10. Calibration & RF Auto Test Program (Hot Kimchi)
LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
10.1 Configuration of HOT KIMCHI
10.1.1 Configuration of directory
10.1.2 Description of basic files
1. Cal_Setup_Test.xml : Parameter Setup File for Calibration items
2. NstProcdure_CU515_001.xml : Scenario Setup File for Auto RF-Test
3. Spec_KU800_110.xml : Specification File of RF Test items
4. LG_RfCal_Q3G6280Rev_001.dll : RF Calibration DLL File including RF Calibration sequence
functions
5. LG_NsTest_E5515C_239.dll : Auto RF-Test DLL File including RF Test sequence functions
6. DLL_E5515CD.DLL : GPIB DLL File including measuring functions in E5515CD Test Set
Grut
Debug
UI
DLL_PwrControlD.dll
DLL_SerialATD.dll
At_Serial_Cmd.xml
Diag_NV6250_RevB.dll
Diag_NV6275.dll
Diag_NV6280.dll
Diag_NV.dll
DLL_E5515CD.dll
: Directory
: File
Model
LG_CL_015.dll
PwrSupply_Cmd.xml
Auto
Cal
CalAuto
ComLMPLib_2_11.dll
Dll_EzLooksMQ_015.dll
GuiTk115d.dll
HK_32.exe
ShieldBox_DIID.dll
CU920
AutoSetup_200.xml
Common
Cal_Setup_Test.xml
Ezlooks.xml
LG_RfCal_Q3G6280Rev_051.dll
NstProcedure_CU515_001.xml
script_001.xml
Spec_FullBand_013.xml
LG_RfTest_E5515C_107.dll
QMSL_MSVC6R.dll
Hot_Kimchi
LG_NsTest_E5515C_239.dll
LG_UI_Qu6275_004.dll
Multi HK.reg
