LG CU920 - Checking Media FLO Block

- 134 -
4. TROUBLE SHOOTING
4.23 Checking Media FLO Block (The Media FLO function is for CU920)
Media FLO PCB Block
LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
Media FLO
Block
Media FLO ANT
coaxtial cable
MBD1000
RBR1000
BOTTOM
TOP
Media FLO
ANTENNA FEEDING
CONTACT
only CU920
