11. EXPLODED VIEW & REPLACEMENT PART LIST

- 193 -

11.2 Replacement Parts

Note: This Chapter is used for reference, Part order

is ordered by SBOM standard on GCSC

Level Ref No Part Name Part Number Spec Color Remark

1IMT,BAR/FLIP TIMT0001101 Black

2 AAAY00 ADDITION AAAY0240501 Black

3 MPBA00 PAD,BOX MPBA0006101 COMPLEX, (empty), , , , , Without Color

2APEY00 PHONE APEY0434201 Black

3 ACHA00 COVER SUB ASSY,FRONT ACHA0002801 CU920 FOLDER ASSY Black

4 ACGK00 COVER ASSY,FRONT ACGK0102001 Black I

5 MCJK00 COVER,FRONT MCJK0073201 MOLD, PC LEXAN EXL4419, , , , , Black 22

6MICZ00 INSERT MICZ0025701 CASTING, Zn Alloy, , , , , Without Color 10 28

5 MGAZ01 GASKET MGAZ0059901 COMPLEX, (empty), , , , , Without Color 53

5MLAB00 LABEL,A/S MLAB0001102 C2000 USASV DIA 4.0 White 20

5 MLAZ00 LABEL MLAZ0049501 COMPLEX, (empty), , , , , Black 56

5 MTAC00 TAPE,SHIELD MTAC0052401 COMPLEX, (empty), , , , , Black 19

5 MTAC01 TAPE,SHIELD MTAC0064001 COMPLEX, (empty), , , , , Black 55

5 MTAF00 TAPE,MOTOR MTAF0013001 COMPLEX, (empty), , , , , Without Color 18

5 MTAK00 TAPE,CAMERA MTAK0001801 COMPLEX, (empty), , , , , Without Color 24

4 ACGM00 COVER ASSY,REAR ACGM0092701 Black M

5MCCC00 CAP,EARPHONE JACK MCCC0046101 COMPLEX, (empty), , , , , Black 43

5MCCF00 CAP,MOBILE SWITCH MCCF0044601 COMPLEX, (empty), , , , , Black 38

5 MCJN00 COVER,REAR MCJN0069401 MOLD, PC LUPOY SC-1004A, , , , , Black 37

5 MDAD00 DECO,CAMERA MDAD0031001 ELECTROFORMING, Cu, 0.2, , , , Silver 42

5 MGAD00 GASKET,SHIELD FORM MGAD0145701 COMPLEX, (empty), , , , , Silver 34

5 MGAD01 GASKET,SHIELD FORM MGAD0145801 COMPLEX, (empty), , , , , Silver 35

5 MPBT00 PAD,CAMERA MPBT0043301 COMPLEX, (empty), , , , , Black 33

5 MPBZ00 PAD MPBZ0196101 COMPLEX, (empty), , , , , Without Color 51

5 MPBZ01 PAD MPBZ0196201 COMPLEX, (empty), , , , , Without Color 47

5 MTAA00 TAPE,DECO MTAA0139501 COMPLEX, (empty), , , , , Without Color 41

5 MTAB TAPE,PROTECTION MTAB0223701 COMPLEX, (empty), , , , , Black 49

5 MTAD00 TAPE,WINDOW MTAD0070701 COMPLEX, (empty), , , , , Without Color 39

5 MWAE00 WINDOW,CAMERA MWAE0027001 CUTTING, PMMA MR 200, , , , , Black 40

4 ACGZ00 COVER ASSY ACGZ0013801 UPPER ASSY Black D

5 MCJZ00 COVER MCJZ0046601 MOLD, PC LUPOY SC-1004A, , , , , Black 4

6MICZ00 INSERT MICZ0025701 CASTING, Zn Alloy, , , , , Without Color

5 MFBC00 FILTER,SPEAKER MFBC0032201 COMPLEX, (empty), , , , , Black
