- 194 -

11. EXPLODED VIEW & REPLACEMENT PART LIST

LGE Internal Use Only

Only for training and service purposes

Level Ref No Part Name Part Number Spec Color Remark

5 MHGF00 PAD,MIKE MPBH0035201 COMPLEX, (empty), , , , , Black

5 MPBG00 PAD,LCD MPBG0063301 COMPLEX, (empty), , , , , Black 7

5 MPBJ00 PAD,MOTOR MPBJ0042001 CUTTING, BeCu, 0.5, , , , Black 5

5 MPBN00 PAD,SPEAKER MPBN0043501 COMPLEX, (empty), , , , , Black 6

5 MTAD00 TAPE,WINDOW MTAD0070601 COMPLEX, (empty), , , , , Without Color 2

4GMEY00 SCREW MACHINE,BIND GMEY0011201 1.4 mm,3 mm,MSWR3(BK) ,N ,+ ,NYLOK Without Color 29 44

4 MBJL00 BUTTON,SIDE MBJL0042901 COMPLEX, (empty), , , , , Silver

4 MBJL01 BUTTON,SIDE MBJL0043001 COMPLEX, (empty), , , , , Silver 26

4 MBJZ00 BUTTON MBJZ0011401 MOLD, PC LUPOY SC-1004A, , , , , Black 8

4MFEA00 FRAME,SHIELD MFEA0017101 MOLD, PC LUPOY SC-1004A, , , , , Black 31

4 MIDZ00 INSULATOR MIDZ0138501 COMPLEX, (empty), , , , , Green 52

4 MIDZ01 INSULATOR MIDZ0138601 COMPLEX, (empty), , , , , Green

4 MLAZ00 LABEL MLAZ0038303 PRINTING, (empty), , , , , White 54

4 MTAB00 TAPE,PROTECTION MTAB0179301 COMPLEX, (empty), , , , , Without Color 48 A

4 MTAC00 TAPE,SHIELD MTAC0065301 COMPLEX, (empty), , , , , Black 58

4 MWAC00 WINDOW,LCD MWAC0090501 COMPLEX, (empty), , , , , Black 1 B

4 SACY00 PCB ASSY,FLEXIBLE SACY0070701 15 E

5 SACE00 PCB ASSY,FLEXIBLE,SMT SACE0064901

6 SACC00

PCB ASSY,FLEXIBLE,SMT

BOTTOM

SACC0042901

7 CN101

CONNECTOR,BOARD TO

BOARD

ENBY0032401 14 PIN,0.4 mm,ETC , ,H=1.5, Header

7 MIC101 MICROPHONE SUMY0010602

UNIT ,-42 dB,6.15*3.76*1.25 ,Silicon mic , ,-42 ,300

,OMNI ,[empty] ,6.15*3.76*1.25 ,SMD
