4. TROUBLE SHOOTING
- 111 -
VREG_MSMC
VREG_MSME
VREG_MSMA
VREG_TCXO_2.85V
(C175)
TCXO-IN
: 19.2Mhz
(C160)
X700 : 32.768Khz
VREG_MSMP
PM6650IC
I/O CON
VA801
PS_HOLD
47pC808
0.1uC809
ZD1
RSB6.8CST2R
VA801 EVLC14S02050
47p
C807
33u
C806
EVLC14S02050VA803 EVLC14S02050VA802
D801
PSD12-LF
INSTPAR
USB_VBUS
PM_ON_SW_N
UART_TX
UART_RX
MAIN Bottom (near MSM6281IC)
MAIN Bottom (near PM6650IC)
VA801
