11. EXPLODED VIEW & REPLACEMENT PART LIST
- 196 -
Level Ref No Part Name Part Number Spec Color Remark
7 C132 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C140 CAP,CHIP,MAKER ECZH0001002 0.5 pF,50V ,B ,NP0 ,TC ,1005 ,R/TP
7C144 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C145 CAP,CERAMIC,CHIP ECCH0000117 27 pF,50V,J,NP0,TC,1005,R/TP
7C146 CAP,CERAMIC,CHIP ECCH0000108 7 pF,50V,D,NP0,TC,1005,R/TP
7C147 CAP,TANTAL,CHIP ECTH0002002
33 uF,10V ,M ,L_ESR ,2012 ,R/TP ,; , ,[empty] ,[empty] ,
,-55TO+125C , ,2.2X1.1X1.1MM ,[empty] ,[empty]
,[empty]
7C149 CAP,CHIP,MAKER ECZH0000844 68 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C151 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
7C152 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
7C153 CAP,CERAMIC,CHIP ECCH0000120 39 pF,50V,J,NP0,TC,1005,R/TP
7C154 CAP,CHIP,MAKER ECZH0000846 8.2 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
7C165 CAP,CERAMIC,CHIP ECCH0000110 10 pF,50V,D,NP0,TC,1005,R/TP
7C166 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C168 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
7 C500 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7 C501 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C505 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C506 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C507 CAP,CHIP,MAKER ECZH0000841 56 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C508 CAP,CHIP,MAKER ECZH0000841 56 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C509 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C600 CAP,CERAMIC,CHIP ECCH0000120 39 pF,50V,J,NP0,TC,1005,R/TP
7 C601 CAP,CHIP,MAKER ECZH0004402
100000 pF,16V ,Z ,X7R ,TC ,1005 ,R/TP , , ,[empty]
,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
7 C602 CAP,CERAMIC,CHIP ECCH0000120 39 pF,50V,J,NP0,TC,1005,R/TP
7 C603 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 C604 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 C714 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
7C800 CAP,CERAMIC,CHIP ECCH0000112 15 pF,50V,J,NP0,TC,1005,R/TP
7C805 CAP,CERAMIC,CHIP ECCH0000163 47 nF,10V,K,X5R,HD,1005,R/TP
7C806 CAP,TANTAL,CHIP ECTH0005201
33 uF,6.3V ,M ,L_ESR ,2012 ,R/TP , , ,[empty] ,[empty] ,
,[empty] , ,2.2X1.1X1.1MM ,[empty] ,[empty] ,[empty]
7C809 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C810 CAP,CERAMIC,CHIP ECCH0000163 47 nF,10V,K,X5R,HD,1005,R/TP
7 C811 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C812 CAP,CERAMIC,CHIP ECCH0000110 10 pF,50V,D,NP0,TC,1005,R/TP
7 C900 CAP,CHIP,MAKER ECZH0003103
0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
