If the height of the cupboard is below
850mm, you should remove the top table
by unscrewing the 2 screws.
(Two from rear)
CAUTION
1. Lay the dishwasher on its back.
2. Adjust the legs to the required height
as shown in below figure.
1. Before sliding the dishwasher into the
cupboard opening, all necessary height
and balancing adjustments should be
made using a spanner.
2. Slide the dishwasher into the cabinet,
opening carefully. Make sure that the
drain hose inside the cabinet is not kinked
or stretched.
Adjust
leg
8
INSTALLATION INSTRUCTIONS
Preparing the dishwasher for
installation
Installing the dishwasher in
cupboard
