S90QY Change List
PART BEFORE ( SP9YA ) AFTER ( S90QY )
HW -
1. SoC : MT8531
2. PMIC : NA
3. AMP : TPA3118
- DNR : 102dB
- P-idle : 1.2W
- Gain : 20 / 26/ 32/ 36 Db
4. Touch : TOUCHCORE 380
5. Trans : ER4220 250uH 0.1ohm
FEELUX CO.,LTD
1. MT8532D
※ SoC Cost VI
※ Network Standby ErP regulatory satisfaction
(2W)
※ Securing the number of audio channels.
2. MT6393BN (PM IC)
※ PM IC application according to SOC change.
3. TPA3221
- DNR : 109dB
- P-idle : 0.46W
- Gain : 18 / 24 /30 / 34 dB
※ Change considering the high effi ciency of
power consumption.
4. MSP430FR2533IRHBR
5. ER4220 250uH 0.1ohm
Change Turn
( Before 10T -> new 8T)
FEELUX CO.,LTD
MECHANISM
Meterial PC+ABS / SPCC(Grill) PC+ABS / Front Jersey
SIZE 1200 x 57 x 145 mm 1200 x 63 x 135 mm
Remocon O
SOUND
Output / CH 520 W / 5.1.2Ch 570 W / 5.1.3Ch
Unit
1. Main Set
- Front L/R : 20mm TW x 2ea,
40x100 WF x 2ea
- Center : 20mm TW x 1ea,
40x100 WF x 1ea
- Center Top : 無
- Top L/R : 2.5inch WF x 2ea
- Side L/R : 40x100 WF x 2ea
2. SWF : 7 inch WF x 1ea
1. Main Set
- Front L/R : 20mm TW x 2ea,
52x99 WF x 2ea
- Center : 2 inch WF x 1ea
- Center Top : 20mm TW x 1ea
- Top L/R : 2.5inch WF x 2ea
- Side L/R : 2 inch WF x 2ea
2. SWF : 8 inch WF x 1ea
SW
Main
Function
BT, Wi-Fi, HDMI, Optical, USB, e-ARC
Works with Google / Alexa, Airplay2 *APR/VLLM apply, Spotiry Connect
ELECTIRCAL
Main IC MT8531 (MTK) MT8532 (MTK)
AMP IC TPA3118 (TI) TPA3221 (TI)
Earc IC Sil9437 (In SOC)
Micom A33G526 (ABOV)
COMPARISON LIST
To Next Page
