5-3
Copyright © 2022 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
Wireless
Module
RX
Serial
Flash
1MB
SPI
PWM IC
I2S
AMP IC
RL
RR
Main Device
TX
AMP PDN
AMP SD/OTW
RST
I2C
LED RED/GREEN
PWM_ADATA
BLOCK DIAGRAM
