SPECIFICATIONS
 GENERAL
Power Requirement Refer to the main label.
Power Consumption Refer to the main label.
Dimensions (W x H x D) Approx. 1200.0 mm x 63.0 mm x 135.0 mm (including the base)
(47.2 inch x 2.5 inch x 5.3 inch)
Operation Temperature Range 5 °C - 40 °C (41 °F to 104 °F)
Operation Humidity Range 5 % - 60 % RH
Bus Power Supply (USB) 5 V 500 mA
Available Digital Input Audio Sampling
Frequency 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Available Digital Input Audio format Dolby Digital, Dobly Digital Plus, Dolby TrueHD, Dolby Atmos,
DTS Digital Surround, DTS-HD HRA, DTS-HD MA, DTS:X,
IMAX DTS, IMAX DTS:X, PCM
 INPUT/OUTPUT
OPTICAL IN 3.0 V (p-p), (optical audio connection terminal) × 1
HDMI IN 19-pin (Type A, HDMI™ connection terminal) × 1
HDMITV (eARC / ARC) 19-pin (Type A, HDMI™ connection terminal) × 1
4K resolution is supported for 4K sources applied with HDCP 2.3.
 AMPLIFIER (RMS output)
Total 570 W RMS
Front 45 W RMS × 2 (Impedance: 4 Ω, THD 10 %)
Center 40 W RMS (Impedance: 4 Ω, THD 10 %)
Sides 45 W RMS × 2 (Impedance: 4 Ω, THD 10 %)
Top 45 W RMS × 2 (Impedance: 4 Ω, THD 10 %)
Top center 40 W RMS (Impedance: 4 Ω, THD 10 %)
Subwoofer 220 W RMS (Impedance: 3 Ω, THD 10 %)
 WIRELESS SUBWOOFER
Power Requirement Refer to the main label on the Wireless Subwoofer.
Power Consumption Refer to the main label on the Wireless Subwoofer.
Type 1-way 1 speaker
Impedance 3 Ω
Rated power 220 W RMS
Max. Power 440 W RMS
Dimensions (W x H x D) Approx. 201.7 mm x 407.0 mm x 403.0 mm
(7.9 inch x 16.0 inch x 15.8 inch)
 SYSTEM
Wireless LAN (Internet antenna) 802.11a/b/g/n Wi-Fi network compatible
Rear Speakers and Wireless Receiver [SPQ8-S (SPQ8-S, S78S2-S)] (Sold Separately)
 WIRELESS RECEIVER
Power Requirement Refer to the main label on the wireless receiver.
Power Consumption Refer to the main label on the wireless receiver.
Rear power 70 W RMS x 2 (3 Ω at 1 kHz, THD 10 %)
Dimensions (W x H x D) Approx. 175.0 mm x 61.0 mm x 175.0 mm
(6.9 inch x 2.4 inch x 6.9 inch)
 REAR SPEAKERS
Type 1-way 1 speaker
Impedance 3 Ω
Rated power 70 W RMS
Max. power 140 W RMS
Dimensions (W x H x D) Approx. 100.0 mm x 140.0 mm x 100.0 mm
(3.9 inch x 5.5 inch x 3.9 inch)
• Design and specifications are subject to change without notice.
