- 10 -
5. BOTTOM BRACKET REMOVAL
1) Remove three screws (a).
2) Remove four screws (b).
3) Remove the Bottom Bracket.
6. MAIN BOARD ASSEMBLY REMOVAL
1) Remove three screws (a).
2) Remove three screws (b).
3) Release two latches (c) from the Main Board
Assembly.
(b)
(a)
(b)
(b)
(c)
(c)
(a)
Bottom Bracket
