14)
Adjust R-DRIVE and G-DRIVE command to white
balance x=0.281
±
0.003 and y=0.311
±
0.003 on the
White Balance Meter with PC arrow keys.
15)
Adjust SUB-CONTRAST command to 51
±
1FL of the
color 15,0 box pattern (70x70mm) luminance at
mode 7 and save in color 1.
16)
Display color 15,0 full white patten at Mode 7.
17)
COLOR ADJ. → LUMINANCE → ABL command.
18)
Adjust ABL to 41
±
1FL of the luminance.
19)
Exit from the program.
5. Adjustment for Focus.
1) Set the Brightness and Contrast to max position.
2) Display H character in full screen at Mode 7.
3) Adjust two Focus control on the FBT that focus
should be the best condition.
