LG EV700 - Page 18

- 18 -
NO VIDEO
(POWER INDICATOR ON)
CHECK
POWER INDICATOR
GREEN or ORANGE?
CHECK
D712 ANODE
(-120V)?
CHECK
G1 VOLTAGE?
(-10~20V)
TROUBLE IN
D712
TROUBLE IN
D926, Q925 (6.3V)
TROUBLE IN
Q801~Q806
DPM MODE
(NO H and/or V SYNC)
ORANGE
NO
GREEN
YES
YES
NO
3. NO RASTER
