LG EV700 - Page 37

MODEL: EV700 DATE: 1999. 3. 16.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
IC923 0ISS780500F IC, SAMSUNG ELECTRONICS, KA7805
IC925 0ISS781200F IC, SAMSUNG ELECTRONICS, KA7812
or FB401 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM
FB401 6210TCT003J CORE (CIRC), BEAD, HF55 TDK-K 2.6*6.0MM AXIAL52MM
FB402 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM
or FB402 6210TCT003J CORE (CIRC), BEAD, HF55 TDK-K 2.6*6.0MM AXIAL52MM
FB403 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM
or FB403 6210TCT003J CORE (CIRC), BEAD, HF55 TDK-K 2.6*6.0MM AXIAL52MM
FB701 125-155L CORE (CIRC), BEAD, BFS3580A0FG SAMWHA 3.5*8.0MM
or FB701 6210TCT003L CORE (CIRC), BEAD, HF70 TDK-K 3.5*9.0MM AXIAL52MM
FB702 125-022J CORE (CIRC), BEAD, FERRITE KQ-1 JS 3.5*5.0MM AXIAL62MM
FB703 125-155F CORE (CIRC), BEAD, BFD3580R2FG SAMWHA 3.5*8.0MM
L702 150-518N COIL, CHOKE, DR14*20 180UH 0.12*25MM 57.5T
L703 150-L05N COIL, LINEARITY, DR14*15 14*6T 5.6UH 0.12*30MM 17.5T
L704 125-155K CORE (CIRC), BEAD, BFS3550A0FG SAMWHA 3.5*5.0MM
or L704 6210TCT003K CORE (CIRC), BEAD, HF70 TDK-K 3.5*5.0MM AXIAL52MM
L705 150-985U COIL, CHOKE, DR15*25(C:8.5) 3.0MH 0.45MM 235.5T D/D
L706 150-985G COIL, CHOKE, DR8*11 10MH 0.13MM 568.5T R/CENTER
L901 6200TLT002A FILTER(CIRC), LINE, RING 19*6*13H 1.0MH 0.5MM 22T CB770
Q101 0TR350200AA TRANSISTOR, 2SC3502 BK SANYO TO126 NPN
Q102 0TR390409CA TRANSISTOR, 2N3904 TP SAMSUNG TO92 NPN
Q103 0TR485009AA TRANSISTOR, BF485 TP PHILIPS TO92 NPN
Q104 0TR488009AA TRANSISTOR, BF488 TP PHILIPS TO92 PNP
Q401 0TR945009AA TRANSISTOR, KSC945C-Y TP SAMSUNG TO92 NPN EPI.
or Q401 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q501 0TR471009AA TRANSISTOR, KSD471AC-Y TP SAMSUNG TO92 NPN
or Q501 0TR320209AA TRANSISTOR, KTC3202-Y(KTC1959) TP KEC TO92 NPN
Q502 0TR564009AB TRANSISTOR, KSB564AC-YTA TP SANSUNG TO92 PNP
or Q502 0TR127009AA TRANSISTOR, KTA1270-Y(KTA562TM) TP KEC TO92 PNP
Q503 0TR564009AB TRANSISTOR, KSB564AC-YTA TP SANSUNG TO92 PNP
or Q503 0TR127009AA TRANSISTOR, KTA1270-Y(KTA562TM) TP KEC TO92 PNP
Q504 0TR945009AA TRANSISTOR, KSC945C-Y TP SAMSUNG TO92 NPN EPI.
or Q504 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q601 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q602 0TR928009AB TRANSISTOR, KSA928A-Y TP SAMSUNG TO92L PNP
or Q602 0TR127309AA TRANSISTOR, KTA1273-Y(KTA966A) TP KEC TO92L PNP
Q603 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q704 0TR945009AA TRANSISTOR, KSC945C-Y TP SAMSUNG TO92 NPN EPI.
or Q704 0TR319809AA TRANSISTOR, KTC3198-Y(KTC1815) TP KEC TO92 NPN
Q705 0TR200009AB TRANSISTOR, KTC200-Y TP KEC TO92 NPN
Q706 0TR252700AB TRANSISTOR, BU2527AX BK PHILIPS SOT339 H-OUT TR
Q707 0TR564009AB TRANSISTOR, KSB564AC-YTA TP SANSUNG TO92 PNP
or Q707 0TR127009AA TRANSISTOR, KTA1270-Y(KTA562TM) TP KEC TO92 PNP
- 37 -
TRANSISTORs
COILs & COREs
