LG EV700 - Page 44

MODEL: EV700 DATE: 1999. 3. 16.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
R939 0RD0472Q609 RESISTOR, FIXED CARBON FILM, 47 1/4W(3 5% TA52
R941 0RD1001Q609 RESISTOR, FIXED CARBON FILM, 1K 1/4W(3 5% TA52
R942 0RD0472A609 RESISTOR, FIXED CARBON FILM, 47 OHM 1/2 W (7.0) 5% TA52
R943 0RD1502Q609 RESISTOR, FIXED CARBON FILM, 15K 1/4W(3 5% TA52
R944 0RN6802G409 RESISTOR, FIXED METAL FILM, 68K 1/4W 1 TA52
R945 0RN3901F409 RESISTOR, FIXED METAL FILM, 3.90K 1/6W 1% TA52
VR101 180-037G VOLUME, EVN-DCAA03B13 (MEC),1KB
VR701 180-035G VOLUME, EVN-DJAA03B13 (MEC),1KB
VR901 180-035D VOLUME, EVN-DJAA03B32 (MEC),300B
F1 430-858C FUSE HOLDER, AFC-520 BAE EUN TA
F2 430-858C FUSE HOLDER, AFC-520 BAE EUN TA
F901 131-040C FUSE,TIME LAG, 3150MA 250V 5.2X20 CY/GL UL / CSA LITTEL
J91 0RD0102Q609 RESISTOR, FIXED CARBON FILM, 10 1/4W(3 5% TA52
PG1 302-987A SHIELD, TERMINAL EARTH
PG2 302-987A SHIELD, TERMINAL EARTH
RL901 141-039A RELAY, JW2HN-DC12V MATSUSHITA 250VAC 5A 12V 44MA
SC901 6200TJB001D FILTER(CIRC),EMI, 02ME4E2 DELTA 25MH BLACK
SG701 165-004A SPARK GAP, AG20PT 152F-L3N/S-23 HANDOK RADIAL BULK
T701 6174Z-1012C FBT (FLY BACK TRANSFORMER), FMMTC61
T702 6170TCZ002A TRANSFORMER,HORIZONTAL DRIVER, EE2519,2.9MH
T703 6170TCZ001A TRANSFORMER, SMPS, H-DRIVE,EI2218,3.8MH
T901 6170TMZ064A TRANSFORMER, SMPS, EER4045 195000000H 16PIN CG771B
TH901 6322TB090AA THERMISTOR, PTC, PT11P62D090Q290 DAEWOO +30%/-20%
WG2 387-P91A CONNECTOR ASSY, UL1015 AWG22
X401 6202TTB001A CRYSTAL, HC-49/U SUNNY E 6.000000MHZ 30PPM 16PF BK
C301 0CZZTFT001Z CAPACITOR, ECQB1H104JM3 104J 50V TP5.0 MATSUSHITA
or C301 181-288B CAPACITOR, POLYESTER, MKT 100V 104JTR PHS26104
C302 0CE1076D618 CAPACITOR, AL.ELECTROLYTIC, 100M SMS 10V M FM5
C303 0CZZTFT001Z CAPACITOR, ECQB1H104JM3 104J 50V TP5.0 MATSUSHITA
or C303 181-288B CAPACITOR, POLYESTER, MKT 100V 104JTR PHS26104
C306 0CZZTFT001X CAPACITOR, ECQB1H683JM3 683J 50V TP5.0 MATSUSHITA
or C306 181-288K CAPACITOR, POLYESTER, MKT 100V 683JTR PHS26683
C307 0CH3104K946 CAPACITOR, CHIP[CERAMIC LD-LESS HD], 100000PF 50V
C308 0CE1076D618 CAPACITOR, AL.ELECTROLYTIC, 100M SMS 10V M FM5
C309 0CK2230K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.022UF 50V
C310 0CN2230H949 CAPACITOR, TUBULAR(HIGH DIELEC), 22000P 25V Z FTA52
C311 0CK2230K945 CAPACITOR, CERAMIC (HIGH DIELECTRIC), 0.022UF 50V
C312 0CE1076F618 CAPACITOR, AL.ELECTROLYTIC, 100UF SMS 16V M TP(5)
C313 0CH3104K946 CAPACITOR, CHIP[CERAMIC LD-LESS HD], 100000PF 50V Z
C314 0CH3104K946 CAPACITOR, CHIP[CERAMIC LD-LESS HD], 100000PF 50V Z
C315 0CH3104K946 CAPACITOR, CHIP[CERAMIC LD-LESS HD], 100000PF 50V Z
- 44 -
OTHERs
VIDEO BOARD
CAPACITORs
