LG EV700 - Page 49

MODEL: EV700 DATE: 1999. 3. 16.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
R361 0RH5600D622 RESISTOR, CHIP, 560 1/10W 5 D.R/TP
R362 0RH5101D622 RESISTOR, CHIP, 5.1K 1/10W 5 D.R/TP
R363 0RH2702D622 RESISTOR, CHIP, 27K 1/10W 5 D.R/TP
R364 0RD1000Q609 RESISTOR, FIXED CARBON FILM, 100 1/4W(3 5% TA52
R365 0RD0102Q609 RESISTOR, FIXED CARBON FILM, 10 1/4W(3 5% TA52
R366 0RH1200D622 RESISTOR, CHIP, 120 1/10W 5 D.R/TP
R367 0RH1200D622 RESISTOR, CHIP, 120 1/10W 5 D.R/TP
R368 0RH1200D622 RESISTOR, CHIP, 120 1/10W 5 D.R/TP
R370 0RD0102Q609 RESISTOR, FIXED CARBON FILM, 10 1/4W(3 5% TA52
R371 0RD3301Q609 RESISTOR, FIXED CARBON FILM, 3.30K 1/4W(3 5% TA52
SC301 381-094L SOCKET (CIRC), CPT, 033-0-7700-41 METALLO 10PIN 14/360
SG301 6918TAT001B SPARK GAP, AXIAL, DSP-201M-A21F MMC AXIAL TAPPING
SG302 6918TAT001B SPARK GAP, AXIAL, DSP-201M-A21F MMC AXIAL TAPPING
SG303 6918TAT001B SPARK GAP, AXIAL, DSP-201M-A21F MMC AXIAL TAPPING
SG304 6918TAT001B SPARK GAP, AXIAL, DSP-201M-A21F MMC AXIAL TAPPING
SG305 165-004A SPARK GAP, AG20PT 152F-L3N/S-23 HANDOK RADIAL BULK
C201 0CN1040K949 CAPACITOR, TUBULAR(HIGH DIELEC), 0.1M 50V Z F TA52
C202 0CN1040K949 CAPACITOR, TUBULAR(HIGH DIELEC), 0.1M 50V Z F TA52
C203 0CN1040K949 CAPACITOR, TUBULAR(HIGH DIELEC), 0.1M 50V Z F TA52
C204 0CE106BK638 CAPACITOR, AL.ELECTROLYTIC, 10U KME 50V M FM5 TP5
C210 0CN1040K949 CAPACITOR, TUBULAR(HIGH DIELEC), 0.1M 50V Z F TA52
C211 0CN1040K949 CAPACITOR, TUBULAR(HIGH DIELEC), 0.1M 50V Z F TA52
D201 0DL300009AE LED, LTL-30EFJ TP LITEON RED D = 5 TWO COLOR
D210 0DZ560009CE DIODE, ZENER, MTZJ5.6B TP ROHM-K DO34 500MW 5.6V 5MA
J201 971-0016 WIRE, JUMP, TIN HDC 0.60H
J203 971-0016 WIRE, JUMP, TIN HDC 0.60H
L201 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM
L210 125-155J CORE (CIRC), BEAD, BFS2550A0FG SAMWHA 2.5*5.0MM
P201 6602T20003J WAFER, 35363-1010 MOLEX 2.0mm R/A
Q201 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
Q202 0TR114009AB TRANSISTOR, DTC114ES TP ROHM-K SPT NPN
R201 0RD5100Q609 RESISTOR, FIXED CARBON FILM, 510 1/4W(3 5% TA52
R202 0RD4701Q609 RESISTOR, FIXED CARBON FILM, 4.70K 1/4W(3 5% TA52
R203 0RD5100Q609 RESISTOR, FIXED CARBON FILM, 510 1/4W(3 5% TA52
R204 0RD4701Q609 RESISTOR, FIXED CARBON FILM, 4.70K 1/4W(3 5% TA52
R205 0RD1300Q609 RESISTOR, FIXED CARBON FILM, 130 1/4W(3 5% TA52
R215 0RD1001Q609 RESISTOR, FIXED CARBON FILM, 1K 1/4W(3 5% TA52
R217 0RD3600Q609 RESISTOR, FIXED CARBON FILM, 360 1/4W(3 5% TA52
R218 0RD3600Q609 RESISTOR, FIXED CARBON FILM, 360 1/4W(3 5% TA52
R219 0RD2700Q609 RESISTOR, FIXED CARBON FILM, 270 1/4W(3 5% TA52
SW201 140-058D SWITCH, TACT, SKHV10911A LGEC NON 12 20 HORIZENTAL
VR201 6110T1H003B VOLUME, “EC11B20244 240K F L17 “”ENCORD+S/W,20C/20P,
- 49 -
CONTROL BOARD
OTHERs
