LG EV700 - Page 55

- 55 -
KA7805 (KA7808, KA7812) Positive Voltage Regulator 5V (8V, 12V)
INPUT OUTPUT
GND
1 3
2
SERIES
PASS
ELEMENT
SOA
PROTECTION
THERMAL
PROTECTION
CURRENT
GENERATOR
REFERENCE
VOLTAGE
STARTING
CIRCUIT
ERROR
AMPLIFIER
1: Input
2: GND
3: Output
1
2
3
AT24C08 2-Wire Serial CMOS EEPROM
AT24C08
1
2
3
4
8
7
6
5
Vcc
Wp
SCL
SDA
A0
A1
A2
GND
Pin Configuration
Pin Configuration
1
8
PIN NAME
A0 to A2
SDA
SCL
WP
FUNCTION
Address Inputs
Serial Data
Serial Clock Input
Write Protect
BLOCK DIAGRAM
PIN NAME
E0-E2
SDA
SCL
WC
Vcc
Vss
FUNCTION
Chip Enable Inputs
Serial Data Address Input/Output
Serial Clock
Write Control
Supply Voltage
Ground
M24C08 8K SERIAL I
2
C BUS EEPROM
8
7
6
5
8
7
6
5
Vcc
WC
SCL
SDA
E0
E1
E2
Vss
M2404C08
1
8
