29
①
Lift and separate the cabinet cover.
① The cabinet cover clamp is removed and the
gasket is released.
② Two screws are unscrewed.
③ The Door Lock S/W is disconnected form the
wiring connector and the strap.
SWITCH ASSY, DOOR LOCK
※※
NOTE: When assembling the CABINET
COVER, connect the Door S/W connector.
