LG Flatron F700P User Manual

DATE: 2002. 5. 14.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D308 0DS124409AA 1SS244 TP ROHM KOREA
D309 0DS124409AA 1SS244 TP ROHM KOREA
D310 0DS124409AA 1SS244 TP ROHM KOREA
D311 0DS124409AA 1SS244 TP ROHM KOREA
D312 0DS124409AA 1SS244 TP ROHM KOREA
D313 0DS124409AA 1SS244 TP ROHM KOREA
D314 0DS124409AA 1SS244 TP ROHM KOREA
D315 0DS124409AA 1SS244 TP ROHM KOREA
D318 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D319 0DR140059DA 1N4005TB52 TP LITEON DO41 600V
D401 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D402 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D404 0RD4701Q609 4.70K 1/4W(3 5% TA52
D405 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D451 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D452 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D453 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D454 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D456 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D457 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D501 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
D502 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
D503 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
D504 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
D505 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
D506 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
D507 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
D508 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
D509 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
D510 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
D511 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D512 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
D513 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
D514 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
D515 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
D601 0DD100009DE RGP10G TP G.I DO204AL 400V 1A
D602 0DD100009DE RGP10G TP G.I DO204AL 400V 1A
D611 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D701 0DR400409AB UF4004 TP G.I DO204AL 400V 1A
D702 0DR400409AB UF4004 TP G.I DO204AL 400V 1A
D703 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D704 0DD100009DE RGP10G TP G.I DO204AL 400V 1A
D706 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D707 0DD100009DA RGP10J TP G.I DO204AL 600V 1A
D708 0DRFJ00011A YG339D6F208 FUJI ST TO220 -400
D709 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D731 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D732 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D733 0DD400709CB UF4007 TP G.I DO204AL 1000V 1
D734 0DD400709CB UF4007 TP G.I DO204AL 1000V 1
D735 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D736 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D737 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D738 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D739 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D771 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D772 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
DATE: 2002. 5. 14.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D773 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D801 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D802 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D803 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D804 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D805 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D808 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D811 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D812 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D831 0DR260400AA S2L60-4004P15 BK SHINDENGEN NO
D833 0DR140059DA 1N4005TB52 TP LITEON DO41 600V
D834 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D835 0DD140009AA EK14 V(1) TP SANKEN E/EO-TMD 4
D836 0DD140009AA EK14 V(1) TP SANKEN E/EO-TMD 4
D837 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D838 0DR200000EA FMQ-G2FMS BK SANKEN NON 1500V
D839 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D840 0DD100009DA RGP10J TP G.I DO204AL 600V 1A
D861 0DD140009AA EK14 V(1) TP SANKEN E/EO-TMD 4
D901 0DD360000DB D3SB60 SHINDENKEN
D902 0DD400709CB UF4007 TP G.I DO204AL 1000V 1
D903 0DD100009DE RGP10G TP G.I DO204AL 400V 1A
D904 0DD100009DA RGP10J TP G.I DO204AL 600V 1A
D905 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D906 971-0054 TIN 50MM TAPING
D908 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D910 0DR153979AA 1N5397GP TP G.I DO201AD 600V 1
D920 0DRSD00079A D2L20U SHINDENGEN TP DO-204AC
D921 0DRSD00079A D2L20U SHINDENGEN TP DO-204AC
D922 0DR320400AA S3L20U-4004P15 BK SHINDENGEN N
D923 0DR360000AB D3L60 BK SHINDENGEN ITO220 6
D924 0DR260400AA S2L60-4004P15 BK SHINDENGEN NO
D925 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D926 0DR260400AA S2L60-4004P15 BK SHINDENGEN NO
D927 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D928 971-0054 TIN 50MM TAPING
D929 0DD100009DE RGP10G TP G.I DO204AL 400V 1A
D940 0DD400709CB UF4007 TP G.I DO204AL 1000V 1
D941 0DD100009DE RGP10G TP G.I DO204AL 400V 1A
D942 0DR520000AA D5LC20U BK SHINDENGEN ITO220
D943 0DD100009DE RGP10G TP G.I DO204AL 400V 1A
D946 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
ZD201 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD202 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD203 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD303 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD306 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD402 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD403 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD404 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD405 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD407 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD408 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD409 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD410 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD703 0DZ510009BE GDZ5.1B TP GRANDE DO34 500MW 5
ZD711 0DZ910009AH MTZJ9.1B TP ROHM-K DO34 500MW
- 26 -

LG Flatron F700P Specifications

Display

colours	16.7 million
pitch	0.24
max resolution	1920 x 1440 @ 65 Hz
recommended resolution	1280 x 1024 @ 85 Hz

Frequency

horizontal frequency	30 ~ 98 KHz
vertical frequency	50 ~ 160 Hz

Power

power supply	AC 90-264 V, 47~63 Hz
DPMS power consumption (on)	<83 W
DPMS power consumption (stand-by)	<8 W
DPMS power consumption (off)	<5 W

Weight and Dimensions

visual area	325 x 244 mm
dimensions	415 x 432 x 413 mm (net)
weight	17 kg (net), 20.5 kg (box)
