LG Flatron F700P User Manual

- 27 -
DATE: 2002. 5. 14.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
ZD712 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD802 0DZ180009BD GDZJ18B TP GRANDE DO34 0.5W 18
ZD804 0DZ180009BD GDZJ18B TP GRANDE DO34 0.5W 18
ZD901 0DZ240009BJ GDZJ24B TP GRANDE DO34 500MW 2
ZD902 0DZ470005AA MTZ 4.7B TP ROHM-K DO34 500MW
IC301 0IPRPNV009A NT68275-00027 NOVATEK 16P, DIP
IC302 0IPRPNS008A LM1267NA NATIONAL SEMICONDUCTO
IC303 0IPRPNS007A LM2463TA NATIONAL SEMICONDUCTO
IC304 0IPRPNS005A LM2480NA NATIONAL SEMICONDUCTO
IC401 0IZZTSZ179A WT62PI WELTREND 42 ST MTP EB99
IC402 0ISG240860A M24C08-BN6 8DIP BK 8K SERIAL I
IC501 0ITI204600B TUSB2046B 32PQFP R/TP USB HUB
IC502 0ITI204400A TPS2044DR 16SOP TP QUAD POWER
IC503 0ITI764330A TPS76433DBVR SOT23(DBV) TP 0.1
IC601 0ISG817200A TDA8172
IC801 0IPRPPH005A TDA4841PS PHILIPS 32P,SDIP ST
IC802 0IMI625010A M62501P 16P4 BK INTERFACE PWM
IC901 0ISS384300A KA3843B 8P SDIP BK PWM CONTROL
IC902 0IPMGFF001A ICE2B265 INFINEON 8 DIP ST SMP
IC904 0ISS781200F KA7812
IC906 0ILI817000E LTV-817M B 4P BK PHOTO COUPLER
IC916 0ILI817000E LTV-817M B 4P BK PHOTO COUPLER
IC917 0IKE431000B KIA431 (TP)
L304 0LA1000K119 100UH K 2.3*3.4 TP
L305 0LA0390K119 0.39UH K 2.3*3.4 TP
L306 0LA0390K119 0.39UH K 2.3*3.4 TP
L307 0LA0390K119 0.39UH K 2.3*3.4 TP
L308 971-0054 TIN 50MM TAPING
L309 971-0054 TIN 50MM TAPING
L310 971-0054 TIN 50MM TAPING
L501 125-155P BFS2550R2FG SAMWHA 2.5*5.0MM R
L701 6140TBZ009C NO CORE 10UH 0.12*15MM 50.5T F
L801 6140TYZ011B - GET DR14*15 EB990G H-LIN
L805 150-985P DR12*15 6MH 0.25MM 365.5T H-
L806 150-985N DR10*10 4.7UH 0.16MM 322.5T
L901 6140TBZ032B EE42SI PFC 49MH 0.42MM 230 +/-
L910 150-985F DR10*10 10UH 0.5MM 14.5T (PFC)
FB201 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB301 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB302 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB303 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB304 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB305 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB306 125-022J FERRITE KQ-1 JS 3.5*5.0MM AXIA
FB307 125-022J FERRITE KQ-1 JS 3.5*5.0MM AXIA
FB308 125-022J FERRITE KQ-1 JS 3.5*5.0MM AXIA
FB309 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB310 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB312 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB313 125-155K BFS3550A0FG SAMWHA 3.5*5.0MM A
FB314 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
DATE: 2002. 5. 14.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
FB315 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB316 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB317 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB401 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB402 125-155N BFD3565R2FG SAMWHA 3.5*6.5MM R
FB403 125-155L BFS3580A0FG SAMWHA 3.5*8.0MM A
FB841 125-155P BFS2550R2FG SAMWHA 2.5*5.0MM R
FB902 125-155H BFS3510A0FG SAMWHA 3.5*10MM AX
FB903 125-155C BFD3514R2FG SAMWHA 3.5*14MM RA
FB904 125-155H BFS3510A0FG SAMWHA 3.5*10MM AX
FB905 125-155C BFD3514R2FG SAMWHA 3.5*14MM RA
FB906 125-155H BFS3510A0FG SAMWHA 3.5*10MM AX
FB907 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
Q301 0TR390409CA 2N3904 TP SAMSUNG TO92 NPN
Q302 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q450 0TR131009BA BFQ 131 TP PHILIPS SOT54 NPN V
Q451 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q452 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q453 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO92
Q454 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q455 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q456 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO92
Q457 0TR564009AB KSB564AC-YTA TP SANSUNG TO92 P
Q458 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO92
Q459 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q611 0TR320709AA KTC3207(KTC2482) TP KEC TO92L
Q701 0TR320509AB KTC3205-Y(KTC2236A) TP KEC TO9
Q704 0TFFN10003B INFINEON SPA07N60C3 ST TO220F
Q705 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO92
Q706 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q707 0TR390409CA 2N3904 TP SAMSUNG TO92 NPN
Q708 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q721 0TR390409CA 2N3904 TP SAMSUNG TO92 NPN
Q722 0TR390600CA 2N3906 TP SAMSUNG TO92 NPN
Q723 0TR390409CA 2N3904 TP SAMSUNG TO92 NPN
Q724-L 0TR463300AB 2SC4633(LS-CB11) BK SANYO LS-
Q725-R 0TRFC10001A FAIRCHILD KSC5042F-YDTU ST TO2
Q771 0TR920009AB KSP92 TP SAMSUNG TO92 HIGH VOL
Q801 0TR558900BA 2SC5589(LG,W/M) BK TOSHIBA TO3
Q802 0TR471009AA KSD471AC-Y TP SAMSUNG TO92 NP
Q803 0TR564009AB KSB564AC-YTA TP SANSUNG TO92 P
Q806 0TR471009AA KSD471AC-Y TP SAMSUNG TO92 NP
Q807 0TR564009AB KSB564AC-YTA TP SANSUNG TO92 P
Q808 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q810 0TR114009AB DTC114ES TP ROHM-K SPT NPN
Q832 0TF283509AA 2SK2835(TP) TP TOSHIBA 200V 5A
Q833 0TF306000AA 2SJ306 BK SANYO -250V -3A TO2
Q834 0TR231609AA KSC2316-Y TP SAMSUNG TO92L NP
Q836 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5A
Q837 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5A
Q838 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5A
Q839 0TF640000CA IRFS640A BK SAMSUNG 200V 9A T
Q841 0TR114009AB DTC114ES TP ROHM-K SPT NPN
Q842 0TR114009AB DTC114ES TP ROHM-K SPT NPN
COILs & COREs
ICs
TRANSISTORs

LG Flatron F700P Specifications

Display

colours	16.7 million
pitch	0.24
max resolution	1920 x 1440 @ 65 Hz
recommended resolution	1280 x 1024 @ 85 Hz

Frequency

horizontal frequency	30 ~ 98 KHz
vertical frequency	50 ~ 160 Hz

Power

power supply	AC 90-264 V, 47~63 Hz
DPMS power consumption (on)	<83 W
DPMS power consumption (stand-by)	<8 W
DPMS power consumption (off)	<5 W

Weight and Dimensions

visual area	325 x 244 mm
dimensions	415 x 432 x 413 mm (net)
weight	17 kg (net), 20.5 kg (box)
