LG Flatron F700P User Manual

DATE: 2002. 5. 14.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
Q843 0TR114009AB DTC114ES TP ROHM-K SPT NPN
Q844 0TR114009AB DTC114ES TP ROHM-K SPT NPN
Q901 0TFFN10003C INFINEON SPA07N60C3(E8153) ST
Q903 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q912 0TR127309AA KTA1273-Y(KTA966A) TP KEC TO92
Q913 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q914 0TR928009AB KSA928A-Y TP SAMSUNG TO92L PNP
Q915 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q920 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
R201 0RD1001Q609 1K 1/4W(3 5% TA52
R202 0RD1600Q609 160 1/4W(3 5% TA52
R203 0RD2200Q609 220 1/4W(3 5% TA52
R204 0RD2200Q609 220 1/4W(3 5% TA52
R205 0RD1001Q609 1K 1/4W(3 5% TA52
R206 0RD1600Q609 160 1/4W(3 5% TA52
R207 0RD3300Q609 330 1/4W(3 5% TA52
R208 0RD3300Q609 330 1/4W(3 5% TA52
R209 0RD5600Q609 560 1/4W(3 5% TA52
R210 0RD3600Q609 360 1/4W(3 5% TA52
R211 0RD5100Q609 510 1/4W(3 5% TA52
R301 0RD0752Q609 75 1/4W(3 5% TA52
R302 0RD0752Q609 75 1/4W(3 5% TA52
R303 0RD0752Q609 75 1/4W(3 5% TA52
R304 0RD0332Q609 33 1/4W(3 5% TA52
R305 0RD0332Q609 33 1/4W(3 5% TA52
R306 0RD0332Q609 33 1/4W(3 5% TA52
R307 0RD5601Q609 5.60K 1/4W(3 5% TA52
R308 0RD1002Q609 10K 1/4W(3 5% TA52
R309 0RD5601Q609 5.60K 1/4W(3 5% TA52
R310 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R311 0RN1002F409 10K 1/6W 1 TA52
R312 0RD0472Q609 47 1/4W(3 5% TA52
R313 0RD1000Q609 100 1/4W(3 5% TA52
R314 0RD1001Q609 1K 1/4W(3 5% TA52
R315 0RD1000Q609 100 1/4W(3 5% TA52
R316 0RD1000Q609 100 1/4W(3 5% TA52
R317 0RD1002Q609 10K 1/4W(3 5% TA52
R318 0RD1001Q609 1K 1/4W(3 5% TA52
R319 0RD1000Q609 100 1/4W(3 5% TA52
R320 0RD1000Q609 100 1/4W(3 5% TA52
R321 0RD1002Q609 10K 1/4W(3 5% TA52
R322 0RD1501Q609 1.50K 1/4W(3 5% TA52
R323 0RD1102Q609 11K 1/4W(3 5% TA52
R324 0RD1000Q609 100 1/4W(3 5% TA52
R325 0RD1002Q609 10K 1/4W(3 5% TA52
R326 0RD1000Q609 100 1/4W(3 5% TA52
R327 0RD2201Q609 2.20K 1/4W(3 5% TA52
R328 0RD2201Q609 2.20K 1/4W(3 5% TA52
R329 0RD2201Q609 2.20K 1/4W(3 5% TA52
R330 0RD1001Q609 1K 1/4W(3 5% TA52
R331 0RD0472Q609 47 1/4W(3 5% TA52
R332 0RD0472Q609 47 1/4W(3 5% TA52
R333 0RD0472Q609 47 1/4W(3 5% TA52
R334 0RD1000Q609 100 1/4W(3 5% TA52
DATE: 2002. 5. 14.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R335 0RD1000Q609 100 1/4W(3 5% TA52
R336 0RD1500Q609 150 1/4W(3 5% TA52
R337 0RD1800Q609 180 1/4W(3 5% TA52
R338 0RD1200Q609 120 1/4W(3 5% TA52
R339 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R340 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R341 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R342 0RD0332A609 33 OHM 1/2 W (7.0) 5% TA52
R343 0RD0332A609 33 OHM 1/2 W (7.0) 5% TA52
R344 0RD0332A609 33 OHM 1/2 W (7.0) 5% TA52
R347 0RD1000Q609 100 1/4W(3 5% TA52
R359 0RD0102Q609 10 1/4W(3 5% TA52
R401 0RD3300Q609 330 1/4W(3 5% TA52
R402 0RD1000Q609 100 1/4W(3 5% TA52
R405 0RD4701Q609 4.70K 1/4W(3 5% TA52
R406 0RD4701Q609 4.70K 1/4W(3 5% TA52
R407 0RD1000Q609 100 1/4W(3 5% TA52
R412 0RD1000Q609 100 1/4W(3 5% TA52
R413 0RD2202Q609 22K 1/4W(3 5% TA52
R414 0RD2202Q609 22K 1/4W(3 5% TA52
R415 0RD2202Q609 22K 1/4W(3 5% TA52
R416 0RD2202Q609 22K 1/4W(3 5% TA52
R419 0RN4701F409 4.70K 1/6W 1% TA52
R420 0RD4701Q609 4.70K 1/4W(3 5% TA52
R421 0RD2001Q609 2K 1/4W(3 5% TA52
R422 0RD4701Q609 4.70K 1/4W(3 5% TA52
R423 0RD1000Q609 100 1/4W(3 5% TA52
R424 0RN2001F409 2K 1/6W 1% TA52
R425 0RD2001Q609 2K 1/4W(3 5% TA52
R426 0RD2001Q609 2K 1/4W(3 5% TA52
R427 0RD4701Q609 4.70K 1/4W(3 5% TA52
R428 0RD1000Q609 100 1/4W(3 5% TA52
R429 0RD1000Q609 100 1/4W(3 5% TA52
R430 0RD1801Q609 1.80K 1/4W(3 5% TA52
R431 0RD1801Q609 1.80K 1/4W(3 5% TA52
R432 0RD1301Q609 1.30K 1/4W(3 5% TA52
R440 0RD1000Q609 100 1/4W(3 5% TA52
R443 0RD1001Q609 1K 1/4W(3 5% TA52
R451 0RD4701Q609 4.70K 1/4W(3 5% TA52
R452 0RD4701Q609 4.70K 1/4W(3 5% TA52
R453 0RD1500Q609 150 1/4W(3 5% TA52
R454 0RD6201Q609 6.20K 1/4W(3 5% TA52
R455 0RN0270G609 0.27 1/4W 5 TA52
R456 0RD0622A609 62 OHM 1/2 W (7.0) 5% TA52
R457 0RD4701Q609 4.70K 1/4W(3 5% TA52
R458 0RD4701Q609 4.70K 1/4W(3 5% TA52
R459 0RD1500Q609 150 1/4W(3 5% TA52
R460 0RD8201Q609 8.20K 1/4W(3 5% TA52
R461 0RD8201Q609 8.20K 1/4W(3 5% TA52
R462 0RD1500Q609 150 1/4W(3 5% TA52
R463 0RD2201Q609 2.20K 1/4W(3 5% TA52
R464 0RX0472K607 47 OHM 2 W 5% TA62
R465 0RD1001Q609 1K 1/4W(3 5% TA52
R473 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R493 0RD1000Q609 100 1/4W(3 5% TA52
R494 0RD1000Q609 100 1/4W(3 5% TA52
R501 0RH1502D622 15K 1/10W 5 D.R/TP
- 28 -
RESISTORs

LG Flatron F700P Specifications

Display

colours	16.7 million
pitch	0.24
max resolution	1920 x 1440 @ 65 Hz
recommended resolution	1280 x 1024 @ 85 Hz

Frequency

horizontal frequency	30 ~ 98 KHz
vertical frequency	50 ~ 160 Hz

Power

power supply	AC 90-264 V, 47~63 Hz
DPMS power consumption (on)	<83 W
DPMS power consumption (stand-by)	<8 W
DPMS power consumption (off)	<5 W

Weight and Dimensions

visual area	325 x 244 mm
dimensions	415 x 432 x 413 mm (net)
weight	17 kg (net), 20.5 kg (box)
