1. PICTURE TUBE
Size : 19 inch (Flat Slot Mask)
DefIection Angle : 90°
Neck Diameter : 29.1 mm
Strip Pitch : 0.24 mm
Diagonal Size : 457.5 mm
View Size : 366.0 x 274.5 mm
Face Treatment : AR-ASC (Anti-Reflective and
Anti-Static Coating)
2. SIGNAL
2-1. Horizontal & Vertical Sync
1) Input Voltage Level: Low= ≤0.8V, High= ≥2.1V
2) Sync Polarity : Positive or Negative
2-2. Video Input Signal
1) Voltage Level : 0~0.7 Vp-p
a) Color 0, 0 : 0 Vp-p
b) Color 7, 0 : 0.467 Vp-p
c) Color 15, 0 : 0.7 Vp-p
2) Input Impedance : 75 Ω
3) Video Color : R, G, B Analog
4) Signal Format : Refer to the Timing Chart
2-3. Signal Connector
15 Pin D-Sub Connector
2-4. Scanning Frequency
Horizontal : 30~111 kHz
Vertical : 50~160 Hz
3. POWER SUPPLY
3-1. Power Range
AC 100~120/200~240V, 50/60HZ, 2.5/1.2A
AC 200~240V, 50/60Hz, 1.2A (PFC version)
3-2. Power Consumption
4. DISPLAY AREA
4-1. Active Video Area :
• Max Image Size - 366.0 x 274.5mm (14.40" x 10.80")
• Preset Image Size - 350 x 262 mm (13.78" x 10.31")
4-2. Display Color : Full Colors
4-3. Display Resolution : 1600 Dots x 1200Lines/85Hz
4-4. Video Bandwidth : 235MHz
5. ENVIRONMENT
5-1. Operating Temperature: 0°C~40°C (32°F~103°F)
(Ambient)
5-2. Relative Humidity : 10%~90%
(Non-condensing)
5-3. Altitude : 10,000 ft
6. DIMENSIONS (with TILT/SWIVEL)
Width : 466.6 mm (18.37")
Depth : 472.5 mm (18.60")
Height : 474 mm (18.66")
7. WEIGHT (with TILT/SWIVEL)
Net Weight : 24.0 kg (51.82 lbs)
Gross Weight : 28 kg (61.74 lbs)
8. USB Specifications
USB Standard :
Rev. 1.0 complied self-powered hub
Downstream power supply
: 500mA for each (MAX)
Communication speed : 12 Mbps (Full), 1.5 Mbps (Low)
USB port : 1 Upstream port
4 Downstream ports
CONTENTS
SPECIFICATIONS
- 2 -
SPECIFICATIONS ................................................... 2
SAFETY PRECAUTIONS ........................................ 3
TIMING CHART ....................................................... 4
OPERATING INSTRUCTIONS ................................ 5
CONTROL LOCATIONS ......................................... 8
WIRING DIAGRAM ................................................. 9
DISASSEMBLY ..................................................... 10
BLOCK DIAGRAM ................................................. 11
DESCRIPTION OF BLOCK DIAGRAM...................12
ADJUSTMENT ...................................................... 14
TROUBLESHOOTING GUIDE .............................. 16
EXPLODED VIEW.................................................. 24
REPLACEMENT PARTS LIST .............................. 26
PIN CONFIGURATION .......................................... 34
SCHEMATIC DIAGRAM......................................... 35
PRINTED CIRCUIT BOARD................................... 37
MODE
MAX
NORMAL
STAND-BY
SUSPEND
OFF
H/V SYNC
OFF/ON
ON/OFF
OFF/OFF
POWER CONSUMPTION (USB)
less than 135W (150W)
less than 103W (118W)
less than 8W (20W)
less than 8W (20W)
less than 1W (20W)
LED COLOR
GREEN
GREEN
AMBER
AMBER
