- 20 -
5. NO VERTICAL DEFLECTION
NO V-DEFLECTION
(ONE HORIZONTAL LINE)
CHECK
IC601 Pin 2
(15V) ?
CHECK
IC601 PIN 4
(-15V)?
TROUBLE IN
T901 15V LINE
TROUBLE IN
T901 -15V LINE
TROUBLE IN
IC601, V-CIRCUIT
NO
NO
YES
YES
CHECK
IC701 PIN 12
(SAWTOOTH WAVE)?
TROUBLE IN
IC701
NO
YES
