LG Flatron F900P User Manual

- 29 -
DATE: 2002. 7. 24.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D999 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
ZD101 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD102 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD103 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD104 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD105 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD106 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD107 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD108 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD201 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD201 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD202 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
ZD202 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD203 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
ZD203 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD204 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD205 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
ZD206 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
ZD207 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
ZD208 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
ZD209 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD210 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
ZD211 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
ZD212 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD213 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD214 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
ZD215 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323 20
ZD303 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD306 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD401 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD402 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD403 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD502 0DZ120009AF MTZJ12B TP ROHM-K DO34 500MW 1
ZD701 0DZ110009AD MTZJ11B TP ROHM-K DO34 500MW 1
ZD721 0DZ110009AD MTZJ11B TP ROHM-K DO34 500MW 1
ZD761 0DZ180009BD GDZJ18B TP GRANDE DO34 0.5W 18
ZD841 0DZ180009BD GDZJ18B TP GRANDE DO34 0.5W 18
ZD851 0DZ750009AG MTZJ7.5B TP ROHM-K DO34 0.5W 7
ZD852 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD901 0DZ510009BE GDZ5.1B TP GRANDE DO34 500MW 5
ZD931 0DZ620009AP P6KE200A GENERAL SEMICONDUCTOR
ZD932 0DZ620009AL GDZJ6.2B TP GRANDE DO34 0.5W 6
IC101 0IPRPSS001A S1D2507B01 SAMSUNG ELECTRONICS
IC201 0ITI204600B TUSB2046B(SN2046B) 32PQFP R/TP
IC202 0ITI204400A TPS2044DR 16SOP TP QUAD POWER
IC203 0ITI764330A TPS76433DBVR SOT23(DBV) TP 0.1
IC301 0IPRPNV009A NT68275-00027 NOVATEK 16P, DIP
IC302 0IPRPNS018A LM1262NA NATIONAL SEMICONDUCTO
IC303 0IPRPNS019A LM2462TA NATIONAL SEMICONDUCTO
IC304 0IPRPNS005A LM2480NA NATIONAL SEMICONDUCTO
IC401 0IZZTSZ205A WT62P2 WELTREND 42P,SDIP ST FB
IC403 0ISG240860A M24C08-BN6 8DIP BK 8K SERIAL I
IC404 0IPH740000D N74F00N 14P DIP BK NAND GATE
IC501 0ISS455800H KA4558 8P DIP BK OP AMP
DATE: 2002. 7. 24.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
IC601 0ISG817200A TDA8172
IC701 0IPRPPH005A TDA4841PS PHILIPS 32P,SDIP ST
IC702 0INS353000A LF353N OP-AMP
IC801 0IMI625010A M62501P 16P4 BK INTERFACE PWM
IC901 0ISS384200A KA3842B (PWM)
IC902 0IPMGPF008A TOP243Y POWER INTEGRATION TO22
IC903 0ILI817000E LTV-817M B 4P BK PHOTO COUPLER
IC904 0ILI817000E LTV-817M B 4P BK PHOTO COUPLER
IC905 0ILI817000E LTV-817M B 4P BK PHOTO COUPLER
IC951 0IKE431000B KIA431 (TP)
IC952 0ISH608300A PQ6RD083 4P BK 6.3V VOL. REGUL
IC971 0ISS781200K KA78R12-STU TO220(4L) BK L/DRO
IC991 0IKE431000B KIA431 (TP)
L101 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
L201 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
L304 0LA1000K119 100UH K 2.3*3.4 TP
L305 0LA0150K119 AXIAL TAE YANG 0.15UH 10% A 2.
L306 0LA0150K119 AXIAL TAE YANG 0.15UH 10% A 2.
L307 0LA0150K119 AXIAL TAE YANG 0.15UH 10% A 2.
L771 150-985N DR10*10 4.7UH 0.16MM 322.5T
L772 6140TYZ011F - GET H-LIN 2.1UH FB910G
L774 150-985P DR12*15 6MH 0.25MM 365.5T H-
L831 6140TBZ009C NO CORE 10UH 0.12*15MM 50.5T F
L901 150-A50F SQ2930 6MH MIN 0.80MM 49T
L951 150-985F DR10*10 10UH 0.5MM 14.5T
FB101 6210TCE001L HB-1T2012-102JT CERATECH 2012M
FB201 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB301 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB302 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB303 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB304 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB305 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB306 971-0054 TIN 50MM TAPING
FB307 971-0054 TIN 50MM TAPING
FB308 971-0054 TIN 50MM TAPING
FB309 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB310 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB312 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB314 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB315 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB316 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB317 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB401 125-155B BFS3580R2FG SAMWHA 3.5*8.0MM R
FB402 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB601 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB761 125-155B BFS3580R2FG SAMWHA 3.5*8.0MM R
FB771 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB772 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB951 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB971 125-155L BFS3580A0FG SAMWHA 3.5*8.0MM A
FB972 125-155L BFS3580A0FG SAMWHA 3.5*8.0MM A
FB973 125-155M BFD3550R2FG SAMWHA 3.5*5.0MM R
FB974 125-155G BFS3550R2FG SAMWHA 3.5*5MM RAD
FB975 125-155F BFD3580R2FG SAMWHA 3.5*8.0MM R
