LG Flatron M1721A User Manual

EXPLODED VIEW PARTS LIST
- 22 -
120
174
200
300
400
410
420
430
440
500
510
520
530
900
910
920
930
EAB32761501
Speaker,Fullrange, L07030A-027 ND35 3W 16OHM 85DB 300HZ 30 X 70 X 22 SOLDER SUNLINK COMPANY
6410TMW004A
Power Cord, UC,LP-45 & H05VV-F 0.75_3C, LS-60_1.87M_BLK LP-45 LS-60 1.87M - 250V 10A H05VV-F 3X0.75MM2 BLACK INMETRO N LONGWELL COMPANY
EAJ32188801 LCD,Module-TFT, LM170E03-TLB3 DRIVER 17.0INCH 1280X1024 300CD COLOR 72% 5/4 800 VS 1 5MS, 160/160, 4LAMP, 2CH-LVDS
EAJ32189001
LCD,Module-TFT, LM190E08-TLB2 DRIVER 19.0INCH 1280X1024 300CD COLOR 72% 5/4 800:1 P7 FACTORY 5MS, 160/160, 2CH-LVDS, 4LAMP
ABJ31008204 Cabinet Assembly, M1721 CL-81 17" CABINET ASSY,RAVEN BLACK, MFT, NTSC(BMF), C/SKD
ABJ31008104 Cabinet Assembly, M1921 CL-81 19" CABINET ASSY, RAVEN BLACK, MFT, NTSC(BMF),C/SKD
ACQ31008404
Cover Assembly,Rear, M1721 CL-81 17" BACK COVER ASSY, RAVEN BLACK, BB2, MFT, Ext. TUNNER, C/SKD
ACQ31008306 Cover Assembly,Rear, M1921 CL-81 19" BACK COVER ASSY, RAVEN BLACK, BB2, MFT, Ext TUNNER, LPL,C/SKD
MEY32043301 Knob, MOLD ABS HF-350 SUB 7 KEY M1921 / M1721 ABS, BLACK
MGJ32111402 Plate,Shield, PRESS SBHG 0.6T METAL EGI M1721 INVERTER SHIELD (C/SKD)
MGJ32111104
Plate,Shield, PRESS SBHG 0.6T METAL EGI M1921 INVERTER SHIELD FOR LPL MODULE (C/SKD)
ADV31008007 Frame Assembly, M1721 CL-81 ETC METAL FRAME ASSY BB2 MFT EXT. TUNNER, C/SKD
ADV31008008 Frame Assembly, M1921 CL-81 ETC METAL FRAME ASSY BB2 MFT EXT. TUNNER, C/SKD
6620K00017B Socket,Power, DAC-11S L2 3P STRAIGHT WIRE BK AC - 10.0A 250.0V -
EBR31651206 PCB Assembly, SUB T.T CL81 Mx21A Brazil CKD control
EBR32541802 PCB Assembly, SUB T.T CL81 Mx21A BMF CKD LED+IR
33139L7001H Main Total Assembly, M1721A-BMF(LPL 5), Brazil CKD BRAND CL-81
EBU30247806 Main Total Assembly, BB2 Brazil,MFT,Ext-Tuner,LPL 5 CKD BRAND CL-81-M1921A
6871TPT318A PCB Assembly,Power, MFT 4-LAMP POWER T.T ETC MFT 4-LAMP BRAND - LGE TV SBU
ACQ31008503 Cover Assembly, M1721/ M1921 CL-81 ETC HINGE COVER ASSY, RAVEN BLACK, C/SKD
MCK32045602 Cover, MOLD ABS HF-350 M1921 / M1721 ABS STAND BODY, BLACK (CKD)
MCK32045701
Cover, MOLD ABS HF-350 M1921 / M1721 ABS STAND HOLDER_CABLE ARRANGEMENT, BLACK
ACQ31009202 Cover Assembly, M1921 / M1721 CL-81 ETC STAND BASE COVER, RAVEN BLACK , C/SKD
Description
Part No.
Ref. No.
* Note: Safety mark
