LG Flatron M1721A User Manual

- 23 -
DATE: 2006. 10. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C101 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C102 0CH3104K566 0805B104K500CT 100nF 10% 50V
C111 0CK105DH56A C2012X7R105KFT 1uF 10% 25V X
C112 0CK105DH56A C2012X7R105KFT 1uF 10% 25V X
C113 0CH5220K416 0805N220J500LT 22pF 5% 50V C
C114 0CH5470K416 0805N470J500LT 47pF 5% 50V C
C115 0CH5470K416 0805N470J500LT 47pF 5% 50V C
C116 0CH5101K416 C2012C0G1H101JT 100pF 5% 50V
C117 0CK105DH56A C2012X7R105KFT 1uF 10% 25V X
C118 0CK105DH56A C2012X7R105KFT 1uF 10% 25V X
C126 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C127 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C129 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C130 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C131 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C132 0CH3104K566 0805B104K500CT 100nF 10% 50V
C134 0CE228ED618 KMG5.0TP10VB2200M 2200uF 20%
C144 0CK105DH56A C2012X7R105KFT 1uF 10% 25V X
C145 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C146 0CE108EH618 KMG5.0TP25VB1000M 1000uF 20%
C153 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C154 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C155 0CC470CK41A C1608C0G1H470JT 47pF 5% 50V
C156 0CH6680K416 C2012C0G1H680JT 68pF 5% 50V
C157 0CC470CK41A C1608C0G1H470JT 47pF 5% 50V
C174 0CH3104K566 0805B104K500CT 100nF 10% 50V
C175 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C176 0CH3104K566 0805B104K500CT 100nF 10% 50V
C177 0CH3104K566 0805B104K500CT 100nF 10% 50V
C178 0CH3104K566 0805B104K500CT 100nF 10% 50V
C180 0CK475DD57A C2012X5R1A475KT 4.7uF 10% 10
C181 0CK475DD57A C2012X5R1A475KT 4.7uF 10% 10
C187 0CH3104K566 0805B104K500CT 100nF 10% 50V
C188 0CH3104K566 0805B104K500CT 100nF 10% 50V
C189 0CC271CK41A C1608C0G1H271JT 270pF 5% 50V
C190 0CH3104K566 0805B104K500CT 100nF 10% 50V
C191 0CH5331K416 0805N331J500LT 330pF 5% 50V
C192 0CH3104K566 0805B104K500CT 100nF 10% 50V
C194 0CH8106F691 MVK4.0TP16VC10M 10uF 20% 16V
C195 0CH8106F691 MVK4.0TP16VC10M 10uF 20% 16V
C196 0CH8106F691 MVK4.0TP16VC10M 10uF 20% 16V
C197 0CH3104K566 0805B104K500CT 100nF 10% 50V
C198 0CC271CK41A C1608C0G1H271JT 270pF 5% 50V
C199 0CC271CK41A C1608C0G1H271JT 270pF 5% 50V
C201 0CH8476H691 MVK8.0TP25VC47M 47uF 20% 25V
C202 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C203 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C204 0CC221CK41A C1608C0G1H221JT 220pF 5% 50V
C205 0CH3474H946 C2012Y5V1E474ZT 470nF -20TO+
C206 0CK224CF56A 0603B224K160CT 220nF 10% 16V
C207 0CK105CF94A 0603F105Z160CT 1uF -20TO+80%
C208 0CK105CF94A 0603F105Z160CT 1uF -20TO+80%
DATE: 2006. 10. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C209 0CH3474H946 C2012Y5V1E474ZT 470nF -20TO+
C210 0CK224CF56A 0603B224K160CT 220nF 10% 16V
C211 0CH3104K566 0805B104K500CT 100nF 10% 50V
C212 0CH3104K566 0805B104K500CT 100nF 10% 50V
C213 0CH3474H946 C2012Y5V1E474ZT 470nF -20TO+
C214 0CK224CF56A 0603B224K160CT 220nF 10% 16V
C215 0CH3474H946 C2012Y5V1E474ZT 470nF -20TO+
C216 0CH3104K566 0805B104K500CT 100nF 10% 50V
C217 0CH3104K566 0805B104K500CT 100nF 10% 50V
C218 0CK224CF56A 0603B224K160CT 220nF 10% 16V
C220 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C221 0CK474CH94A 0603F474Z250CT 470nF -20TO+8
C222 0CK474CH94A 0603F474Z250CT 470nF -20TO+8
C223 0CK105CF94A 0603F105Z160CT 1uF -20TO+80%
C224 0CK474CH94A 0603F474Z250CT 470nF -20TO+8
C225 0CK474CH94A 0603F474Z250CT 470nF -20TO+8
C226 0CE477EH618 KMG5.0TP25VB470M 470uF 20% 2
C227 0CE477EH618 KMG5.0TP25VB470M 470uF 20% 2
C232 0CC470CK41A C1608C0G1H470JT 47pF 5% 50V
C233 0CC470CK41A C1608C0G1H470JT 47pF 5% 50V
C236 0CH5102K416 0805N102J500LT 1nF 5% 50V C0
C237 0CH5102K416 0805N102J500LT 1nF 5% 50V C0
C238 0CH5102K416 0805N102J500LT 1nF 5% 50V C0
C239 0CH5102K416 0805N102J500LT 1nF 5% 50V C0
C3001 0CH3104K566 0805B104K500CT 100nF 10% 50V
C3002 0CH3104K566 0805B104K500CT 100nF 10% 50V
C3004 0CH8106F691 MVK4.0TP16VC10M 10uF 20% 16V
C301 0CH3224K946 C2012Y5V1H224ZT 220nF -20TO+
C3011 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50V
C3012 0CH5470K416 0805N470J500LT 47pF 5% 50V C
C3013 0CH3104K566 0805B104K500CT 100nF 10% 50V
C3014 0CH5470K416 0805N470J500LT 47pF 5% 50V C
C3015 0CK474CH94A 0603F474Z250CT 470nF -20TO+8
C3017 0CK474CH94A 0603F474Z250CT 470nF -20TO+8
C3019 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C302 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C3022 0CH3474H946 C2012Y5V1E474ZT 470nF -20TO+
C3024 0CH5470K416 0805N470J500LT 47pF 5% 50V C
C3026 0CH3474H946 C2012Y5V1E474ZT 470nF -20TO+
C3028 0CH5470K416 0805N470J500LT 47pF 5% 50V C
C303 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C3030 0CC470CK41A C1608C0G1H470JT 47pF 5% 50V
C3031 0CK474CH94A 0603F474Z250CT 470nF -20TO+8
C3032 0CK474CH94A 0603F474Z250CT 470nF -20TO+8
C3033 0CH5470K416 0805N470J500LT 47pF 5% 50V C
C3035 0CK225DK94A CL21F225ZBFNNNE 2.2uF -20TO+
C3036 0CK333CK56A C1608X7R1H333KT 33nF 10% 50V
C3037 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V
C304 0CK224CF56A 0603B224K160CT 220nF 10% 16V
C3040 0CK225DK94A CL21F225ZBFNNNE 2.2uF -20TO+
C3042 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C3043 0CH5470K416 0805N470J500LT 47pF 5% 50V C
C3044 0CK333CK56A C1608X7R1H333KT 33nF 10% 50V
C3045 0CC470CK41A C1608C0G1H470JT 47pF 5% 50V
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
