LG Flatron M1721A User Manual

DATE: 2006. 10. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
Q302 0TR127009AA KTA1270-Y(KTA562TM) PNP -5V
Q303 0TR390409AE KST3904 NPN 6V 60V 40V 200MA
Q304 0TR390409AE KST3904 NPN 6V 60V 40V 200MA
Q305 0TR390409AE KST3904 NPN 6V 60V 40V 200MA
Q402 0TR390409AE KST3904 NPN 6V 60V 40V 200MA
Q701 0TR390409AE KST3904 NPN 6V 60V 40V 200MA
Q704 0TR162309CA KSC1623-Y(MTF) NPN 5V 60V 50
Q715 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V
C740 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R1001 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R1002 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R1003 0RJ1300D477 MCR03EZPF1300 130OHM 1% 1/10
R1004 0RJ0752D477 MCR03EZPF750 75OHM 1% 1/10W
R1005 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R1006 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R1007 0RJ1300D477 MCR03EZPF1300 130OHM 1% 1/10
R1008 0RJ0752D477 MCR03EZPF750 75OHM 1% 1/10W
R1009 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R1010 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R1011 0RJ1300D477 MCR03EZPF1300 130OHM 1% 1/10
R1012 0RJ0752D477 MCR03EZPF750 75OHM 1% 1/10W
R1013 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R1014 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R1017 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R1018 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W 2
R102 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R1023 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R1026 0RH3300D622 MCR10EZHJ331 330OHM 5% 1/8W
R1027 0RH3300D622 MCR10EZHJ331 330OHM 5% 1/8W
R1028 0RH3300D622 MCR10EZHJ331 330OHM 5% 1/8W
R1029 0RH3300D622 MCR10EZHJ331 330OHM 5% 1/8W
R103 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R104 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R1043 0RH1003D622 MCR10EZHJ104 100KOHM 5% 1/8W
R1047 0RH1003D622 MCR10EZHJ104 100KOHM 5% 1/8W
R1048 0RH1801D622 MCR10EZHJ182 1.8KOHM 5% 1/8W
R105 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R107 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R1070 0RH3302D622 MCR10EZHJ333 33KOHM 5% 1/8W
R1071 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R1072 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R1073 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R1074 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R1075 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R1076 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W
R1077 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W
R112 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W
R114 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R115 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W 2
R116 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R117 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R121 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R122 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8W
R126 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W
R130 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W 2
R131 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W 2
R132 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W
R133 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W
R134 0RJ1102D677 MCR03EZPJ113 11KOHM 5% 1/10W
DATE: 2006. 10. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R135 0RJ1102D677 MCR03EZPJ113 11KOHM 5% 1/10W
R136 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R137 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R138 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W
R139 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R140 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R141 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R145 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R146 0RH0472D622 MCR10EZHJ470 47OHM 5% 1/8W 2
R149 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8W
R150 0RJ2001D677 MCR03EZPJ202 2KOHM 5% 1/10W
R151 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W 2
R152 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R153 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R155 0RJ8201D677 MCR03EZPJ822 8.2KOHM 5% 1/10
R156 0RJ8201D677 MCR03EZPJ822 8.2KOHM 5% 1/10
R159 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R161 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R162 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R163 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R164 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R165 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R166 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R167 0RH3300D622 MCR10EZHJ331 330OHM 5% 1/8W
R168 0RH3300D622 MCR10EZHJ331 330OHM 5% 1/8W
R169 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R170 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R172 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R174 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W
R177 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R178 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R179 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R184 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W 2
R191 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W 2
R194 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W 2
R195 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W 2
R196 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W 2
R197 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W 2
R198 0RH0472D622 MCR10EZHJ470 47OHM 5% 1/8W 2
R199 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W 2
R202 0RJ3602D677 MCR03EZPJ363 36KOHM 5% 1/10W
R203 0RJ1502D677 MCR03EZPJ153 15KOHM 5% 1/10W
R204 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10W
R206 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R207 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R208 0RJ1203D677 MCR03EZPJ124 120KOHM 5% 1/10
R215 0RJ1802D677 MCR03EZPJ183 18KOHM 5% 1/10W
R217 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W
R218 0RH4702D622 MCR10EZHJ473 47KOHM 5% 1/8W
R221 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R222 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R223 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R224 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R225 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R226 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R227 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R234 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R248 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R250 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R251 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 20
R252 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W
R253 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
- 26 -
RESISTORs

LG Flatron M1721A Specifications

General

Brand	LG
Model	Flatron M1721A
Category	Monitor
Language	English
