LG Flatron M1721A User Manual

DATE: 2006. 10. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
Q203 0TFRH80001A RK7002T116 N-CHANNEL MOSFET
U303 6620F00017A CCSD-32T-SM 32P 1.27MM SMD T
U405 0TFVI80067A SI3865BDV(E3) N-CHANNEL MOSF
U406 0TF492509AA SI4925DY P-CHANNEL -30V +-20
X301 6202TST003G HC-49/SM5H 24.576MHZ 30PPM 2
C6000 0CN1040K949 CH UP050 F104Z-B-B Z 100nF -
C6001 0CN1040K949 CH UP050 F104Z-B-B Z 100nF -
R6000 0RN8200F409 RN-96T1F820R 820OHM 1% 1/6W
R6001 0RN8200F409 RN-96T1F820R 820OHM 1% 1/6W
R6002 0RN1501F409 RN-96T1F1K50 1.5KOHM 1% 1/6W
R6003 0RN1501F409 RN-96T1F1K50 1.5KOHM 1% 1/6W
R6004 0RN2201F409 RN-96T1F2K20 2.2KOHM 1% 1/6W
R6005 0RN2201F409 RN-96T1F2K20 2.2KOHM 1% 1/6W
SW6000 140-058B EVQPB205K 1C1P 15VDC 0.02A V
SW6001 140-058B EVQPB205K 1C1P 15VDC 0.02A V
SW6002 140-058B EVQPB205K 1C1P 15VDC 0.02A V
SW6003 140-058B EVQPB205K 1C1P 15VDC 0.02A V
SW6004 140-058B EVQPB205K 1C1P 15VDC 0.02A V
SW6005 140-058B EVQPB205K 1C1P 15VDC 0.02A V
SW6006 140-058B EVQPB205K 1C1P 15VDC 0.02A V
SW6007 140-058B EVQPB205K 1C1P 15VDC 0.02A V
ZD6000 0DZ560009CF MTZJ5.6B 5.6V 5.45TO5.73V 40
ZD6001 0DZ560009CF MTZJ5.6B 5.6V 5.45TO5.73V 40
LED500 0DLBE0138AA BL-BUBGE301 ROUND 3MM SUPER
PA5000 6712SCA232A TSOP34838SO1 2.7TO5.5V 1.5MA
C5000 0CH5101K416 C2012C0G1H101JT 100pF 5% 50V
C5001 0CH5101K416 C2012C0G1H101JT 100pF 5% 50V
C5002 0CH5470K416 0805N470J500LT 47pF 5% 50V C
C5003 0CH3104K566 0805B104K500CT 100nF 10% 50V
Q5001 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V
Q5002 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V
R5001 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8W
R5002 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W 2
R5003 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W 2
R5004 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W 2
R5005 0RH2001D622 MCR10EZHJ202 2KOHM 5% 1/8W 2
ZD5000 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80O
- 28 -
OTHERs
CONTROL BOARD
LED & IR BOARD
