4. TROUBLE IN DPM
TROUBLE IN DPM
TROUBLE IN U201
CHECK PC
PC IS GOING
INTO DPM MODE
NO
CHECK H/V SYNC LINE
NO
YES
CHECK P611 AND
R612, SYNC
APPEARED?
CHECK
U201 PIN 16,17
SYNC PULSE
YES
1
H-SYNC
2
V-SYNC
Waveforms
1
2
