- 9 -
Copyright 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
BLOCK DIAGRAM
Analog (R/G/B)
ADC
TMDS RX
MCU
Scaler
LVDS TX
OSD
SSC
Flash ROM
D-SUB
LIPS
Panel
5V
3.3V
Key
Flash ROM
Regulator
5V
3.3V
1.8V
AC input
5V
12V (Ready)
Crystal
