6 _ Air-to-Water Heat Pump
Part 1. Monobloc Unit
4. Specification
Note :
1. Capacities and power inputs are based on the following conditions:
*
1
: Heating conditions - Inlet/Outlet Water Temperature 30°C/35°C; Outdoor Air Temperature 7°CDB/6°CWB
2. Wiring cable size must comply with the applicable local and national code.
3. The specification may be subject to change without prior notice for purpose of improvement.
4. This product contains Fluorinated Greenhouse Gases.
Nominal Capacity and Nominal Input
AHBW036H0 [HM031M]
*1
Capacity
Cooling kW
-
Heating kW
3.00
*1
Power Input
Cooling kW
-
Heating kW
0.73
EER Cooling W/W
-
COP Heating W/W
4.10
Technical Specifications
AHBW036H0 [HM031M]
Water Side
Operation
Range
Cooling
For Fan Coil Unit
Min. ~ Max.
°C DB
-
For under floor
Min. ~ Max.
°C DB
-
Heating
For Fan Coil Unit / Radiator
Min. ~ Max.
°C DB
20 ~ 57
For under floor
Min. ~ Max.
°C DB
20 ~ 57
Water Pump
Type -
Canned type for hot water circulation
Motor Type -
Inverter
Steps of Pumping speed -
-
Power input
Rated
W
45
Water Flow Rate
Min. / Rated
ℓ/min
15.0 / 15.0
Heat
Exchanger
Type -
Brazed Plate HEX
Quantity
1
Number of Plate EA
18
Head Loss Rated kPa
8.25
Water Flow Rate Min
ℓ/min
15.0
Expansion
Vessel
System Water Volume
Max.
ℓ
-
Pre-pressure kPa
-
Piping
Connections
Inlet mm
25.4 (Female)
Outlet mm
25.4 (Female)
Strainer
Mesh size W x H mm x mm
-
Material -
-
Safety Valve Pressure Limit
Upper Limit
bar
-
Devices for Water Circuit
-
-
-
-
Refrigerant Side
Operation Range
(Outdoor Temperature)
Cooling
Min. ~ Max.
°C DB
-
Heating
Min. ~ Max.
°C DB
-20 ~ 30
Compressor
Type -
Hermetic motor
Model
Model x No.
GKT141MBC
Motor Type -
Brushless
Motor Output Rated W x No.
1,500 x 1
Heat Exchanger
(Row x Column x Fins per inch) x No.
-
(2 x 38 x 18) x 1
Refrigerant
Type -
R410A
Precharged Amount g(oz)
750 (26.5)
Control -
Electronic Expansion Valve
Refrigerant Oil
Type -
FVC68D
Charged Volume cc x No.
470
Fan
Type -
Propeller
Air Flow Rate Rated
m
3
/min x No.
32.0 x 1
Fan Motor
Type -
BLDC
Output W x No.
124 x 1
Sound Pressure
Level
Cooling Rated dB(A)
-
Heating Rated dB(A)
47
Sound Power Level
Heating Max. dB(A)
57
Silent Sound Pressure Level
Heating Rated dB(A) 43
Silent Sound Power Level
Heating Max. dB(A) 53
Dimensions Unit
W x H x D
mm
950 x 834 x 330
Weight Unit kg
61.0
Electrical Specifications AHBW036H0 [HM031M]
Outdoor Unit
Power Supply V, Ø, Hz
220-240, 1, 50
Maximum
Running Current
Cooling A
-
Heating A
10.0
Wiring Connections
Power Supply Cable (included Earth)
No x mm
2
3 x 1.0 (H07RN-F)
To Next Page
