LG HT353SD-A2 - IC501 Pin Descriptions (Part 5)

Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2-31
Pin Main Alt. Type Description
6) Audio Mute
7) HSYN/VSYN input
8) C1
1) GPIO9
2) MS_D0 set A
89 GPIO9
InOut 3) SD_CMD set A
4mA, PD 4) ASDATA1
5) ABCK
6) C2
7) RXD1
1) GPIO10
2) SD_CLK set B
3) SD_D0 set A
91 GPIO10
InOut 4) ASDATA0
4mA, PD 5) ALRCK
6) HSYN/VSYN output
7) C3
8) TXD1
1) GPIO11
2) SD_CMD set B
92 GPIO11
InOut 3) MS_BS set B
4mA, PD 4) Audio Mute
5) HSYN/VSYN output
6) C4
93 SPDIF GPIO12
InOut 1) SPDIF output
2mA, PD 2) GPIO12
1) GPIO13
94 GPIO13
InOut 2) SD_D0 set B
4mA, PD 3) ALRCK
4) Audio Mute
5) YUVCLK
