Check connections between
MT1389/L and pick-up head.
YES
YES
YES
YES
YES
Check CD_DVDCT connection
between AM5890 and
MT1389/L.
Check cable connection
on pick-up head.
YES
YES
Proper
signals on A, B, C,
D of MT1389/L.
NO
Check the related circuit on
MT1389/L CD-DVDCT.
Proper
CD-DVDCT signal
on MT1389/L.
Focus on ok?
NO
Check RF signal waveform.
Disc Playback?
NO
NO
Check the related circuit on
MT1389/L.
NO
Check the TRACK connection
on MT1389/L and motor driver.
NO
Check the tracking control amp
circuit on motor driver.
Proper
CD-DVDCT signal
on MT1389/L.
YES
Proper
TRACK signal
on MT1389/L.
YES
TR+ & TR-output
properly?
Track On OK?
