Only for training and service purposes

LGE Internal Use Only

2-31

Pin Main Alt. Type Description

6) Audio Mute

7) HSYN/VSYN input

8) C1

1) GPIO9

2) MS_D0 set A

89 GPIO9

InOut 3) SD_CMD set A

4mA, PD 4) ASDATA1

5) ABCK

6) C2

7) RXD1

1) GPIO10

2) SD_CLK set B

3) SD_D0 set A

91 GPIO10

InOut 4) ASDATA0

4mA, PD 5) ALRCK

6) HSYN/VSYN output

7) C3

8) TXD1

1) GPIO11

2) SD_CMD set B

92 GPIO11

InOut 3) MS_BS set B

4mA, PD 4) Audio Mute

5) HSYN/VSYN output

6) C4

93 SPDIF GPIO12

InOut 1) SPDIF output

2mA, PD 2) GPIO12

1) GPIO13

94 GPIO13

InOut 2) SD_D0 set B

4mA, PD 3) ALRCK

4) Audio Mute

5) YUVCLK
