2-14
Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2. SDRAM CLOCK
1) ES8391 main clock is at 27MHz(X501)
FIG 2-1
1
1
3. TRAY OPEN/CLOSE SIGNAL
1) Tray open/close waveform
FIG 3-1
1
2) Tray close waveform
FIG 3-2
1
2
3
4
2
3
4
DCLK = 93MHz, Vp-p=2.2, Vmax=2.7V
OPENSW(
OPENSW
CLOSESW
OPEN
CLOSE
CLOSESW
OPEN
CLOSE
