LG HT963SA-DP Service Manual

Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2-62 2-63
CIRCUIT VOLTAGE CHART
MPEG (IC501)
Names Pin Numbers Voltage
COREVCC 1.5 16, 48, 79, 124, 185, 188 1.51 V
VD33_DAC 97, 101 3.47 V
VD33_PLL 107 3.47 V
AVD33 109 3.47 V
VD33RF 145,163,183 3.43 V
VD33 1, 14, 30, 46, 62, 77, 95, 119, 133, 186, 203 3.47 V
SDRAM (IC502)
Names Pin Numbers Voltage
VCC33 1, 3, 9, 14, 27, 43, 49 3.47 V
FLASH (IC503)
Names Pin Numbers Voltage
VD33 1, 3, 8 3.47 V
EEPROM (IC504)
Names Pin Numbers Voltage
VD33 8 3.47 V
IPOD (IC507)
Names Pin Numbers Voltage
VCC33 1, 40 3.47 V
ADC (IC201)
Names Pin Numbers Voltage
VCC50 5, 14, 30 4.87 V
VCC33 36, 46 3.47 V
SERVO (IC401)
Names Pin Numbers Voltage
12V_INPUT 12 12.04 V
MVCC50 5, 19 4.86 V
COREVCC1.5 28 1.56 V
ADG884 (IC804)
Names Pin Numbers Voltage
EEP_VCC(VCC50) 1 4.32 V
HDMI TX (IC805)
Names Pin Numbers Voltage
TDVD33 13, 28, 34, 48, 70 3.23 V
TAVD33 23, 38 3.29 V
TDVC18 4, 16, 45, 59, 74 1.8 V
LC87F5R64A (IC101)
Names Pin Numbers Voltage
5V_P 9, 36, 59 5.04 V
TS5A2053 (IC202)
Names Pin Numbers Voltage
VCC50 8 4.87 V
