2-582-57
IC Sym IC Name / Type Vcc / Vdd
IC100
MICOM
R5F100GEAFB#30
TYPE: 48P
VENDER: RENESAS
VDD: 48
•Spec:
VDD: -0.5V~6.5V
•Measured voltage:
VDD: 3.3V
IC101
EEPROM
M24C16-RMN6TP
TYPE: 8P
VENDER: ST
VCC: 8
•Spec:
VCC: 1.8V ~ 5.5V
•Measured voltage:
VCC: 3.28V
IC102
NOR Flash
MX25L2006EM1I-12G(TR)
TYPE: 8P
VENDER: MACRONIX
VCC: 8
•Spec:
VCC: 2.7~3.6V
•Measured voltage:
VCC: 3.38V
IC103
Voltage detector
AZ7027RTRE1
TYPE: 3P
VENDER: BCD
VCC: 1
•Spec:
VCC: Max 18V
•Measured voltage:
VCC: 3.73V
IC200
A/D Converter
PCM1808
TYPE: 14P
VENDER: TI
VCC: 3
VDD: 4
•Spec:
VCC: 4.5V~5.5V
VDD: 2.7V~3.6V
•Measured voltage:
VCC: 5.18V
VDD: 3.41V
IC300
DC-DC
TPS65252RHD
TYPE: 28P
VENDER: TI
Vin1: 8
Vin2: 13
•Spec:
Vin1: 4.5V~18V
Vin2: 4.5V~18V
•Measured voltage:
Vin1: 5.23V
Vin2: 5.23V
IC301
LDO
TJ4220GDP-ADJ
TYPE: 8P
VENDER: HTC
Vin: 3
Vout: 6
•Spec:
Vin: 2.5V~6V
Vout:0.8V~5V
•Measured voltage:
Vin: 5.21V
Vout: 5.15V
IC302
LDO
TJ4220GDP-ADJ
TYPE: 8P
VENDER: HTC
Vin: 3
Vout: 6
•Spec:
Vin: 2.5V~6V
Vout: 0.8V~5V
•Measured voltage:
Vin: 3.73V
Vout: 3.227V
IC303
LDO
TJ4220GDP-ADJ
TYPE: 8P
VENDER: HTC
Vin: 3
Vout: 6
•Spec:
Vin: 2.5V~6V
Vout: 0.8V~5V
•Measured voltage:
Vin: 3.732V
Vout: 3.5V
IC304
LDO
TJ4220GDP-ADJ
TYPE: 8P
VENDER: HTC
Vin: 3
Vout: 6
•Spec:
Vin: 2.5V~6V
Vout: 0.8V~5V
•Measured voltage:
Vin: 3.731V
Vout: 3.373V
IC305
LDO
TJ4220GDP-ADJ
TYPE: 8P
VENDER: HTC
Vin: 3
Vout: 6
•Spec:
Vin: 2.5V~6V
Vout: 0.8V~5V
•Measured voltage:
Vin: 3.733V
Vout: 3.312V
IC Sym IC Name / Type Vcc / Vdd
IC600
PS9860
TYPE: 68P
VENDER: PURSUS
VDD_IO: 17,54,43
VDD_CORE: 6,25,63
VDD_PLL: 68
VIN33_REG1: 34
VIN33_REG2: 66
VOUT12_REG1: 35
VOUT12_REG2: 67
•Spec:
VDD_IO: 2.79V~3.63V
VDD_CORE: 1.08V~1.32V
VDD_PLL: 1.08V~1.32V
VIN33_REG1:
2.97V~3.63V
VIN33_REG2:
2.97V~3.63V
VOUT12_REG1:
1.08V~1.32V
VOUT12_REG2:
1.08V~1.32V
•Measured voltage:
VDD_IO: 3.269V
VDD_CORE: 3.269V
VDD_PLL: 3.269V
VIN33_REG1: 3.269V
VIN33_REG2: 3.269V
VOUT12_REG1: 3.269V
VOUT12_REG2: 3.269V
IC601
DC-DC
TPS54331D
TYPE: 8P
VENDER: TI
Vin: 2
EN: 3
•Spec:
Vin: 3.5V~28V
EN: -0.3V~6V
•Measured voltage:
Vin: 25.62V
EN: 3.228V
IC7000
AMP
TAS5612LADDVR
TYPE: 44P
VENDER: TI
GVDD_AB: 1
GVDD_CD: 22
PVDD_AB: 36,37,38
PVDD_CD: 29,30,31
VDD: 2
DVDD: 8
AVDD: 13
•Spec:
GVDD_AB: -0,3V~13.2V
GVDD_CD: -0,3V~13.2V
PVDD_AB: -0.3V~50V
PVDD_CD: -0.3V~50V
VDD: -0,3V~13.2V
DVDD: -0.3V~4.2V
AVDD: -0.3V~8.5V
•Measured voltage:
GVDD_AB: 12.05V
GVDD_CD: 12.05V
PVDD_AB: 25.63V
PVDD_CD: 25.62V
VDD: 12.15V
DVDD: 3.312V
AVDD: 7.75V
IC7001
AMP
TAS5612LADDVR
TYPE: 44P
VENDER: TI
GVDD_AB: 1
GVDD_CD: 22
PVDD_AB: 36,37,38
PVDD_CD: 29,30,31
VDD: 2
DVDD: 8
AVDD: 13
•Spec:
GVDD_AB: -0,3V~13.2V
GVDD_CD: -0,3V~13.2V
PVDD_AB: -0.3V~50V
PVDD_CD: -0.3V~50V
VDD: -0,3V~13.2V
DVDD: -0.3V~4.2V
AVDD: -0.3V~8.5V
•Measured voltage:
GVDD_AB: 12.04V
GVDD_CD: 12.05V
PVDD_AB: 25.62V
PVDD_CD: 25.62V
VDD: 12.15V
DVDD: 3.341V
AVDD: 7.81V
IC Sym IC Name / Type Vcc / Vdd
IC306
Voltage Regulator
TJ5205SF5-ADJ
TYPE: 5P
VENDER:TEAJIN
Vin: 1
Vout: 5
•Spec:
Vin:2.5V~16V
Vout: MIN 2.0V
•Measured voltage:
Vin: 5.209V
Vout: 5.019V
IC307
LDO
TJ4220GDP-ADJ
TYPE: 8P
VENDER: HTC
Vin: 3
Vout: 6
•Spec:
Vin: 2.5V~6V
Vout:0.8V~5V
•Measured voltage:
Vin: 5.211V
Vout: 3.288V
IC308
DC-DC
TPS54331D
TYPE: 8P
VENDER: TI
Vin: 2
EN: 3
•Spec:
Vin: 3.5V~28V
EN: -0.3V~6V
•Measured voltage:
Vin: 25.77V
EN: 5.2V
IC309
DC-DC
TPS54331D
TYPE: 8P
VENDER: TI
Vin: 2
EN: 3
•Spec:
Vin: 3.5V~28V
EN: -0.3V~6V
•Measured voltage:
Vin: 25.62V
EN: 3.76V
IC501
MPEG
MT8506BAAG
TYPE: 589P
VENDER: MEDIATEKC
DVCC12: K12
DVCC33: G14
AVDD12: N23
AVDD33: R26
DDRVCCIO1: AC3
DDRVREF: N8
•Spec:
DVCC12: 1.14V~1.26V
DVCC33: 3.15V~3.45V
AVDD12: 1.14V~1.26V
AVDD33: 3.15V~3.45V
DDRVCCIO1:
1.425V~1.575V
DDRVREF: 0.775V
•Measured voltage:
DVCC12: 1.190V
DVCC33: 3.367V
AVDD12: 1.190V
AVDD33: 3.367V
DDRVCCIO1: 1.552V
DDRVREF: 0.775V
IC503
DDR
H5TQ1G63EFR-PBC
TYPE: 96P
VENDER: TI
VDD: B2,D9,G7,K2,K8,N1,N9,
R1,R9
VREFCA: M8,H1
VDDQ:A1,A8,C1,C9,D2,E9,E1,
H2,H9
•Spec:
VDD: +1.425V~+1.575V
VREFCA:
0.49*VDD~0.51*VDD
VDDQ: +1.425V~1.575V
•Measured voltage:
VDD: 1.552V
VREFCA: 0.775V
VDDQ: 1.552V
IC504
DDR
H5TQ1G63EFR-PBC
TYPE: 96P
VENDER: TI
VDD:
B2,D9,G7,K2,K8,N1,N9,R1,R9
VREFCA: M8,H1
VDDQ:
A1,A8,C1,C9,D2,E9,E1,H2,H9
•Spec:
VDD:+1.425V~+1.575V
VREFCA:
0.49*VDD~0.51*VDD
VDDQ:+1.425V~+1.575V
•Measured voltage:
VDD: 1.552V
VREFCA: 0.775V
VDDQ: 1.552V
IC505
NAND Flash Memory
H27U4G8F2ETR-BC
TYPE: 48P
VENDER: hynix
VCC: 12,37
•Spec:
VCC: 2.7~3.6V
•Measured voltage:
VCC: 3.366V
CIRCUIT VOLTAGE CHART
Location Spec Measured voltage [V]
C7034,C7003,C7069,C7038
330uF/35V
(105/2000HR)
+25.62V
