1. Turn off the electrical supply and gas supply
going to the range.
2. Remove the griddle, grates, burner caps and
burner heads.
3. Remove all 15 screws from cooktop burner
housings.
4. Disengage 2 front clips using a flat blade screw-
driver.
5. Lift top up at front.
NOTE : Before lowering the top onto the front clips,
line up the burner body and with the cooktop to
replace screws.
3-4
COMPONENT ACCESS
REMOVING THE COOKT
REMOVING THE COOKT
OP PLA
OP PLA
TE
TE
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
