3-7
COMPONENT ACCESS
5. To remove the ignition switch:
a) Remove the manifold panel (See the step 3 on
page 3-5).
b) Pry on the 2 release tabs and slide the switch
off the valve stem.
c) Remove the connector and remove the ignition
switch.
6. To remove the electrode (spark plug):
a) Remove the rear control panel (See the step
3-4 on page 3-2).
b) Remove the connector from the spark module.
c) Remove the wire ring
d) Remove the electrode from the burner
housing.
To Next Page
