LG LHD687 User Manual

Table of Contents4
Table of Contents
1 Getting Started
2 Safety Information
6 Unique Features
6 – Portable In
6 – USB Direct Recording
6 – Full HD up-scaling
6 – Home Theater Speaker ez Setup
6 – Bluetooth®
6 – LG Sound Sync
7 Introduction
7 – Playable Discs
7 – About the “7” Symbol Display
7 – Symbols Used in this Manual
7 – Regional Codes
8 Playable file Requirement
9 Remote control
10 Front panel
11 Rear panel
2 Connecting
12 Attaching the speakers to the unit
13 Positioning the system
14 Connections to Your TV
14 – HDMI Out Connection
15 – What is SIMPLINK?
16 – Video Connection
16 – Resolution Setting
17 Video Output Resolution
17 Optional Equipment Connection
17 – AUX (L/R) INPUT Connection
18 – PORT. IN (Portable Input) Connection
18 – Listening to music from your portable
player or external device
18 – USB Connection
19 – OPTICAL IN connection
19 – Home theater speaker ez setup
19 – Antenna Connection
3 System Setting
20 Adjust the setup settings
20 – OSD Initial language settings - Optional
20 – To display and exit the Setup menu
21 – Language
21 – Display
22 – Audio
23 – Lock (Parental Control)

LG LHD687 Specifications

General

Audio decoders	Dolby Digital
RMS rated power	1250 W
Audio output channels	4.2 channels
Audio formats supported	LPCM
Total Harmonic Distortion (THD)	25 %
3D	No
Video upscaling	Yes
Video formats supported	MPEG, MPEG1, MPEG2, XVID
Analog signal format system	NTSC, PAL
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Playback disc formats	MP3
Optical disc player type	DVD player
Product color	Black
Equalizer modes	Bass Blast, Standart
Power consumption (typical)	145 W
Supported radio bands	PLL
Preset stations quantity	50
Front speaker impedance	3 Ω
Front speaker sensitivity	82 dB
Front speaker woofer diameter (imperial)	3 \
Wireless satellite speakers	-

Weight and Dimensions

Main unit dimensions (WxDxH)	360 x 58 x 298.5 mm
Front speaker dimensions (WxDxH)	233 x 998 x 300 mm
