1. Repair Instruction
a) Replace about PCB.
[SVC Notice] Notice about change of the PCB and Harness
Service Bulletin
Product : Dishwasher
Bulletin # :CDZ201900009-02
Release Date : 2019.08.20
Applicable for Serial Number : 904KWXXXXXXX~
Page 1
Applicable for models
Bulletin Type : SVC Notice Parts Others Applicable only with symptoms with every repair
Symptoms
[SVC Guide] Notice about change of the PCB and Harness
Cause
To apply power separation
- Preventing the defect of Latch ASM
LDT7797 / LDT5665 / LDP6797 / LDP5676 / LDF5545 / LDT7808 / LSDT9908 / LUDP8997
<Refer to the below table>
Before 903KWXXXXXXX After 904XXXXXXX
Extended connectors Old Harness New PCB
New PCB New Harness
- Order the K254 (Need to use the extended connector) - Order the K254 (No need to use the extended connector)
SVC Loc : K254 (Extended connector + New PCB + Protect cover)
