LG LRMVC2306 Series Service Manual

-10-
3-8-3 Cap Decor LED LAMP(Freezer Upper)
1. Unplug refrigerator power cord from electric outlet.
2. Open the refrigerator door to need diassembly.
3. Put flat screwdriver into service hole, remove the cover
of cap decor LED LAMP.
5. Replace LED assembly.
6. Assembly the cover in reverse order.
4. Remove the LED assembly from connector.
Copyright © 2019 LG Electronics Inc. All rights
reserved. Only training and service purposes.
3-8-4 Barrier LED LAMP(Freezer Lower)
1. Unplug refrigerator power cord from electric outlet.
2.
Open the freezer door to need diassembly.
3.
Put flat screwdriver into service hole, remove the cover
of barrier LED LAMP.
5. Replace LED assembly.
6. Assembly the cover in reverse order.
4.
Remove the LED assembly from connector.
