81LIMITED WARRANTY
ENGLISH
Surface is not level
Oven is tipping
Range not leveled
• Check with installer first.
• Use carpenter’s level a to check level.
Anti-tip device not installed correctly
a Approximately 0.65" (16.5 mm)
b Level both sides of range
c Screw must enter wood or concrete
d Anti-tip bracket
e Wall plate
• Check with installer first.
Flames too big on
converted cooktop
(NP
~LP)
The installer missed part of the conversion. (Check 2 parts: regulator, cooktop
valve).
a Regulator
b Cooktop valve
• Check with installer first.
• Refer to installation manual.
Flame is too small
or too large
1. Variable gas pressure
2. Installer did not check
• Check with installer first.
Problem Possible Cause & Prevention
