LG M1921A User Manual

22
Rear Side of the Product
Antenna Cable
(Not included.)
Check if the antenna cable is connected at the rear side of the product
and then, connect the power cord.
When Watching TV
Select an input signal.
Press the INPUT button on the remote control to select the input signal.
Or, press the INPUT button at the top side of the product.
• Select TV
RGB (PC/DTV) IN
ANTENNA IN
AUDIO
(RGB) IN
H/PS-VIDEO
AV IN 2
AV1
(Mono)
VIDEO
AUDI O
LR
ANTENNA IN
1.
2.
INPUT OK
INPUT OK
Connecting to External Devices
Input
TV
AV1
AV2
RGB
OK
Each time you press the Input button it will change to TV AV1 AV2 RGB
If nothing is inputted for several seconds the screen will automatically move to the selected menu.

LG M1921A Specifications

General

HD type	-
Response time	8 ms
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewing angle, vertical	160 °
Contrast ratio (typical)	700:1
Display number of colors	16.78 million colors
Display brightness (typical)	300 cd/m²
Power consumption (off)	2 W
Power consumption (typical)	55 W
Power consumption (PowerSave)	4 W
Plug and Play	Yes
Video out	S-Video
RMS rated power	3 W
Product color	Black

Weight and Dimensions

Depth (without stand)	243 mm
Width (without stand)	445 mm
Height (without stand)	457 mm
Weight (without stand)	5500 g
