LG M1921A User Manual

25
Adjusting the Screen
Name of the Buttons in the Screen Adjustment Unit
OK Button
INPUT Button
• The unit that receives the signal from the remote control.
IR Receiver
• OK button is usually used in choosing the MENU.
When there is no MENU on the screen pushing the OK button will
give the information about the current input source.
TV Television
AV1 SCART
AV2 CVBS, S-Video
RGB D-Sub analog signal
Input
TV
AV1
AV2
RGB
OK
Each time you press the Input button it will change to TV AV1 AV2 RGB
If nothing is inputted for several seconds the screen will automatically move to the selected menu.

LG M1921A Specifications

General

HD type	-
Response time	8 ms
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewing angle, vertical	160 °
Contrast ratio (typical)	700:1
Display number of colors	16.78 million colors
Display brightness (typical)	300 cd/m²
Power consumption (off)	2 W
Power consumption (typical)	55 W
Power consumption (PowerSave)	4 W
Plug and Play	Yes
Video out	S-Video
RMS rated power	3 W
Product color	Black

Weight and Dimensions

Depth (without stand)	243 mm
Width (without stand)	445 mm
Height (without stand)	457 mm
Weight (without stand)	5500 g
