LG M2280D - RGB Connection

ENGLISH
27
MAKING CONNECTIONS
RGB connection
Transmits the analog video signal from your PC to the TV. Connect the PC and the TV with the D-sub 15
pin cable as shown the following illustrations.

If you do not use an optional external speaker, connect the PC to the TV with the supplied audio
cable.
NOTE
1
2
RGB OUT (PC) AUDIO OUT
PC
*Not Provided
