LG M2280D - RS-232 C Configurations

ENGLISH
44
EXTERNAL CONTROL DEVICE SETUP (Only applied to B2B model used in a place like a hotel)
Set ID
Set ID number. "Real Data Mapping"
1
Press MENU to access the main menus.
2
Press the Navigation buttons to scroll to
OPTION and press ENTER.
3
Press the Navigation buttons to scroll to Set ID
and press ENTER.
4
Scroll left or right to select a set ID number
and select Close. The adjustment range is
1-99.
5
When you are finished, press EXIT.
When you return to the previous menu, press
BACK.
RS-232C configurations
7-Wire Configuration
(Serial female-female NULL modem cable)
3-Wire Configurations(Not standard)
PC TV
RXD 2 3 TXD
TXD 3 2 RXD
GND 5 5 GND
DTR 4 6 DSR
DSR 6 4 DTR
RTS 7 8 CTS
CTS 8 7 RTS
D-Sub 9 D-Sub 9
PC TV
RXD 2 3 TXD
TXD 3 2 RXD
GND 5 5 GND
DTR 4 6 DSR
DSR 6 4 DTR
RTS 7 8 CTS
CTS 8 7 RTS
D-Sub 9 D-Sub 9
* REAL DATA MAPPING
1 : Step 0
:
A : Step 10 (Set ID 10)
:
F : Step 15 (Set ID 15)
10 : Step 16 (Set ID 16)
:
63 : Step 99 (Set ID 99)
64 : Step 100
Tint
Step 0 : R50
:
Step 49 : R1
Step 50 : 0
Step 51 : G1
:
Step 100 : G50
Balance
Step 0 : L50
:
Step 49 : L1
Step 50 : 0
Step 51 : R1
:
Step 100 : R50
Color Temperature
Step 0 : W50
:
Step 49 : W1
Step 50 : 0
Step 51 : C1
:
Step 100 : C50
