LG M2762D User Manual

8844
• Press the MENU or EXIT button to close the menu window.
•
Press the RETURN button to move to the previous menu screen.
Select the power indicator on of off.
PPoowweerr iinnddiiccaattoorr OOnn
- Normal Mode : Blue LED On.
- Off Mode : LED Off
- DPM Mode : LED Amber blinking
PPoowweerr iinnddiiccaattoorr OOffff
- Normal Mode : Blue LED Off.
- Off Mode : LED Off
- DPM Mode : LED Amber blinking
POWER INDICATOR
1
Select
OOPPTTIIOONN
.
2
Select
PPoowweerr IInnddiiccaattoorr
.
MENU
OK
Subtitle : Off
Input Label
Key Lock : Off
Set ID : Off
Power Indicator
DDC CI : On
Mode Setting : Home Use
Factory Reset
OPTION
Move
OK
Power Indicator
Subtitle : Off
Input Label
Key Lock : Off
Set ID : Off
Power Indicator
DDC CI : On
Mode Setting : Home Use
Factory Reset
OPTION
Move
OK
Power Indicator
3
Select
OO nn
or
OOffff
.
OK
F
On
G
Close
Power Light
OPTION SETTING

LG M2762D Specifications

General

Pixel pitch	0.3114 x 0.3114 mm
Aspect ratio	16:9
Display diagonal	27 \
Separate H/V sync	Yes
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size diagonal	584.2 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	50000:1
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	170 °
Display brightness (typical)	300 cd/m²
Bandwidth	0.135 GHz
Display viewable area (HxV)	597.7 x 336.2 mm
Display resolution at frequency	1920 x 1080 @ 60 Hz
USB hub version	2.0
RMS rated power	6 W
Certification	TÜV-Typ, CE, UL, CSA, SEMKO, FCC-B
Product color	Black
Market positioning	-
Compliance industry standards	DDC 2B
LED indicators	Stand-by
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
Power consumption (standby)	1 W
Power consumption (typical)	120 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	210 mm
Width (without stand)	654.1 mm
Height (without stand)	494.6 mm
Weight (without stand)	8920 g
