LG MASTER-K Series User Manual

Chapter 2. SPECIFICATIONS
2 - 3
2.2.2 Input Specifications
Item Specifications
5 VDC (7 mA)
12 VDC (7 mA)Rated input voltage / current
24 VDC (13 mA)
5 VDC 4.5 V or more
12 VDC 11 V or more' On ' guarantee voltage
24 VDC 14 V or more
5 VDC 0.8 or less
12 VDC 1.5 V or less' Off ' guarantee voltage
24 VDC 2.5 V or less
2.2.3 Limit Switch (L/S) Input Specifications
Item Specifications
Input voltage 24 VDC
' On ' guarantee voltage 19 VDC or more
' Off ' guarantee voltage 6 VDC or less
On Delay Time 1.5 ms or less
Off Delay Time 2 ms or less
2.2.4 Transistor Output Specifications
Item Specifications
Rated output 24 VDC, 200 mA
Leakage current
50 μA or less
Saturated voltage 1.3V
On Delay Time
50 μs or less
Off Delay Time
50 μs or less
